Services | |
Unterstützte Positionierung | Innen & Außen |
transmission technology | Kabelgebunden |
Eigenschaft | Nachhaltigkeitskonformität |
processor | ARM Cortex-A7 |
Design | |
form factor | Bullet |
attachment type | Wand- / Mast |
Product color | Schwarz, Weiß |
housing material | Aluminium, Polycarbonat (PC) |
International degree of protection (IP code) | IPX4 |
IK-Kodex | IK04 |
Camera | |
viewing angle (horizontal) | 84.4° |
viewing angle (vertical) | 45.4° |
Lens viewing angle, diagonal | 99.8° |
image sensor | |
Sensor-Typ | CMOS |
lens | |
number of lenses | 1 |
night vision | |
LED Type | IR |
Video | |
Maximum resolution | 2688 x 1512 Pixel |
total megapixels | 5 MP |
Video compression formats | H.264, M-JPEG |
Supported graphic resolutions | 2688 x 1512 |
Supported video modes | 1512p |
Up to 30 frames per second | 30 fps |
noise canceling technology | 2D-Rauschunterdrückung, 3D-Rauschunterdrückung |
image quality adjustment | Helligkeit, Kontrast, Schärfe |
Audio | |
network | |
Ethernet interfaces type | 10 Gigabit Ethernet, 100 Gigabit Ethernet |
connections and interfaces | |
Number of Ethernet LAN ports (RJ-45) | 1 |
management functions | |
Managementsoftware | UniFi Protect |
energy | |
energy source | PoE |
Power consumption (max.) | 4 W |
DC output volts | 57 |
operating conditions | |
operating temperatur | -20 - 40 °C |
Operating relative humidity | 0 - 90% |
weight and dimensions | |
diameter | 7,55 cm |
Length (mm) | 74,4 mm |
Weight | 225 g |
scope of delivery | |
number of cameras | 1 |
Technical details | |
Konformitätsbescheinigungen | CE, Eidgenössische Kommunikationskommission (FCC) |
