Services | |
Type | IP-Sicherheitskamera |
Unterstützte Positionierung | Innen & Außen |
transmission technology | Kabelgebunden |
Eigenschaft | Nachhaltigkeitskonformität |
processor | ARM Cortex-A7 |
Design | |
form factor | Dome |
attachment type | Decke/Wand |
Product color | Weiß |
housing material | Aluminium, Polycarbonat (PC), Edelstahl |
protective function | Vandalismussicher |
IK-Kodex | IK06 |
Camera | |
viewing angle (horizontal) | 102.4° |
viewing angle (vertical) | 54.9° |
Lens viewing angle, diagonal | 120.6° |
image sensor | |
number of sensors | 1 |
Image sensor size | 25,4 / 2,4 mm (1 / 2.4") |
Sensor-Typ | CMOS |
lens | |
number of lenses | 1 |
night vision | |
night vision distance | 20 m |
LED Type | IR |
Video | |
Maximum resolution | 2688 x 1512 Pixel |
total megapixels | 4 MP |
Supported video formats | H.264 |
Up to 30 frames per second | 30 fps |
noise canceling technology | 2D-Rauschunterdrückung, 3D-Rauschunterdrückung |
image quality adjustment | Helligkeit, Farbtiefe, Kontrast, DNR, Schärfe |
network | |
Ethernet interfaces type | Schnelles Ethernet |
connections and interfaces | |
Number of Ethernet LAN ports (RJ-45) | 1 |
management functions | |
energy | |
energy source | PoE |
AC input voltage | 37 - 57 V |
Power consumption (standard operation) | 4,2 W |
operating conditions | |
operating temperatur | -20 - 40 °C |
Operating relative humidity | 10 - 90% |
weight and dimensions | |
height | 68,2 mm |
diameter | 6,36 cm |
Weight | 175 g |
scope of delivery | |
number of cameras | 1 |
Supplied cables | LAN (RJ-45) |
Technical details | |
Konformitätsbescheinigungen | CE, Eidgenössische Kommunikationskommission (FCC) |
