Services | |
Type | IP-Sicherheitskamera |
Unterstützte Positionierung | Innen & Außen |
transmission technology | Kabelgebunden |
Eigenschaft | Betriebsanleitung |
certification | FCC, IC, CE |
Design | |
form factor | Patrone (Form) |
attachment type | Decke/Wand/Stange |
Product color | Weiß |
housing material | Aluminium, Polycarbonat (PC) |
International degree of protection (IP code) | IP65 |
IK-Kodex | IK04 |
Camera | |
viewing angle (horizontal) | 35, 109.9° |
viewing angle (vertical) | 19.8, 60° |
Lens viewing angle, diagonal | 40, 127.7° |
image sensor | |
Image sensor size | 25,4 / 2 mm (1 / 2") |
lens | |
Optical zoom | 3x |
focal range | 4.1 - 12.3 mm |
Maximum f-number | 3,3 |
Minimum f-number | 1,53 |
night vision | |
night vision distance | 25 m |
LED Type | IR |
Video | |
Maximum resolution | 3840 x 2160 Pixel |
total megapixels | 8 MP |
Video compression formats | H.264 |
Up to 30 frames per second | 30 fps |
noise canceling technology | 2D-Rauschunterdrückung, 3D-Rauschunterdrückung |
image quality adjustment | Helligkeit, Kontrast, Schärfe |
Audio | |
network | |
Ethernet interfaces type | Schnelles Ethernet |
connections and interfaces | |
Number of Ethernet LAN ports (RJ-45) | 1 |
management functions | |
energy | |
energy source | PoE |
Power consumption (max.) | 10 W |
DC output volts | 37, 48, 54, 57 |
operating conditions | |
operating temperatur | -20 - 50 °C |
Operating relative humidity | 0 - 90% |
weight and dimensions | |
diameter | 8,6 cm |
Length (mm) | 154,3 mm |
Weight | 650 g |
scope of delivery | |
number of cameras | 1 |
