I code | IK06 |
Product colour | White |
Housing material | Polycarbonate (PC) |
Form factor | Dome |
Protection features | Vandal proof |
Mounting Type | Ceiling/wall |
AC input voltage | 37 - 57 V |
Power consumption (typical) | 4.2 W |
Power source type | PoE |
Operating temperature (T-T) | -20 - 40 °C |
Operating relative humidity (H-H) | 10 - 90% |
Reset button | Yes |
Height | 68.2 mm |
Weight | 175 g |
Diameter | 6.36 cm |
Ethernet interface type | Fast Ethernet |
Wi-Fi | No |
Bluetooth | No |
Ethernet LAN | Yes |
Type | IP security camera |
Processor model | ARM Cortex-A7 |
Built-in processor | Yes |
Connectivity Technology | Wired |
Day/night mode | Yes |
Placement supported | Indoor & outdoor |
Infrared (IR) cut-off filter | Yes |
CABLES INCLUDED | LAN (RJ-45) |
Mounting Kit | Yes |
Number of Cameras | 1 |
Screws included | Yes |
Built-in HDD | No |
Ethernet LAN (RJ-45) ports | 1 |
Lens viewing angle, horizontal | 102.4° |
Lens viewing angle, diagonal | 120.6° |
Lens viewing angle, vertical | 54.9° |
Optical sensor size | 25.4 / 2.4 mm (1 / 2.4") |
Number of sensors | 1 |
Sensor type | CMOS |
Frame rate | 30 fps |
Maximum Resolution | 2688 x 1512 pixels |
Video formats supported | H.264 |
Total megapixels | 4 MP |
Image quality adjustment | Contrast |
Privacy masking | Yes |
Noise reduction | Yes |
Noise reduction technology | 2D noise reduction, 3D noise reduction |
Text caption overlay | Yes |
LED type | IR |
Night vision distance | 20 m |
Night Vision | Yes |
Number of lenses | 1 |
Sustainability compliance | Yes |
Compliance certificates | Federal Communications Commission (FCC) |
