| Services | |
| Type | IP-Sicherheitskamera |
| Unterstützte Positionierung | Innen & Außen |
| transmission technology | Kabelgebunden |
| Eigenschaft | Schrauben enthalten |
| processor | ARM Cortex-A7 |
| Design | |
| form factor | Turret |
| attachment type | Decke/Wand |
| Product color | Schwarz |
| housing material | Aluminium, Polycarbonat (PC) |
| protective function | Manipulationssicher, UV-beständig |
| International degree of protection (IP code) | IP66 |
| IK-Kodex | IK04 |
| Camera | |
| viewing angle (horizontal) | 102.4° |
| viewing angle (vertical) | 54.9° |
| Lens viewing angle, diagonal | 120.6° |
| image sensor | |
| number of sensors | 1 |
| Image sensor size | 25,4 / 2,4 mm (1 / 2.4") |
| Sensor-Typ | CMOS |
| lens | |
| number of lenses | 1 |
| night vision | |
| night vision distance | 30 m |
| LED Type | IR |
| Video | |
| Maximum resolution | 2688 x 1512 Pixel |
| total megapixels | 4 MP |
| Supported video formats | H.264 |
| Up to 30 frames per second | 30 fps |
| noise canceling technology | 2D-Rauschunterdrückung, 3D-Rauschunterdrückung |
| image quality adjustment | Helligkeit, Farbtiefe, Kontrast, DNR, Schärfe |
| Audio | |
| network | |
| Ethernet interfaces type | Schnelles Ethernet |
| connections and interfaces | |
| Number of Ethernet LAN ports (RJ-45) | 1 |
| management functions | |
| energy | |
| energy source | PoE |
| AC input voltage | 37 - 57 V |
| Power consumption (standard operation) | 4 W |
| operating conditions | |
| operating temperatur | -30 - 50 °C |
| Operating relative humidity | 0 - 90% |
| weight and dimensions | |
| height | 71,2 mm |
| diameter | 9 cm |
| Weight | 330 g |
| cable length | 0,3 m |
| sustainability | |
| Konformitätsbescheinigungen | CE, Eidgenössische Kommunikationskommission (FCC) |
| scope of delivery | |
| number of cameras | 1 |
| Supplied cables | LAN (RJ-45) |
