Certification | CE-EMC: EN 55032:2015+A1:2020; EN IEC 61000-3-2:2019+A1:2021; EN 61000-3-3:2013+A1:2019+A2:2021; EN 55035:2017+A11:2020; EN 50130-4:2011+A1:2014; CE-LVD: EN 62368-1:2014 |
Product colour | Black |
Current | 1.2 A |
Power source type | DC |
Power consumption (typical) | 53 W |
Storage relative humidity (H-H) | 10 - 93% |
Operating temperature (T-T) | -10 - 55 °C |
Height | 47.6 mm |
Width | 260 mm |
Depth | 232.7 mm |
Weight | 860 g |
Supported resolutions | 3840x2160, 1920x1080, 1280x1024, 1280x720 |
Recording Modes | Motion detection, manual recording, smart recording, alarm |
Backup function | Yes |
Maximum Resolution | 3840 x 2160 pixels |
Video formats supported | H.264+ |
Total megapixels | 12 MP |
Audio codecs | PCM; G711A; G711U; G726 |
Video input channels | 4 channels |
Video motion detection | Yes |
Playback Modes | Instant playback, general playback, event playback, smart playback |
Maximum storage capacity | 20 TB |
HDD interface | Serial ATA |
HDMI ports quantity | 1 |
RCA input | 1 |
USB 2.0 ports quantity | 2 |
Number of SATA connectors | 1 |
Ethernet LAN data rates | 10,100 Mbit/s |
Audio RCA outputs | 1 |
VGA (D-Sub) output ports | 1 |
Power Over Ethernet (PoE) | Yes |
Power over Ethernet (PoE) ports quantity | 4 |
Networking standards | IEEE 802.3 af/at |
