| Built-in processor | Yes |
| Rack capacity | 1U |
| Product colour | Black |
| Power Management | DC 12 V |
| Current | 2 A |
| Operating temperature (T-T) | -10 - 55 °C |
| Storage relative humidity (H-H) | 10 - 93% |
| Storage temperature (T-T) | -20 - 60 °C |
| Depth | 232.5 mm |
| Width | 260 mm |
| Height | 47.6 mm |
| Weight | 810 g |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Client interoperability | ONVIF (Profile S / (Profile T / (Profile G), CGI, SDK |
| Mobile operating systems supported | Android |
| Video motion detection | Yes |
| Maximum Resolution | 3840 x 2160 pixels |
| Operating system installed | Embedded LINUX |
| People counting | Yes |
| Multi-screen | Yes |
| Video formats supported | H.265+ |
| Backup function | Yes |
| Audio codecs | G.711a; G.711u; PCM; G726 |
| Number of simultaneously playbacked channels | 16 channels |
| Video input channels | 16 channels |
| Playback Modes | Instant playback, general playback, event playback, tag playback, smart playback |
| USB 2.0 ports quantity | 2 |
| HDMI output | Yes |
| HDMI ports quantity | 1 |
| VGA (D-Sub) output ports | 1 |
| Audio RCA outputs | 1 |
| Ethernet LAN (RJ-45) ports | 1 |
| RCA input | 1 |
| Maximum storage capacity | 20 TB |
| Number of HDDs supported | 1 |
| Number of SATA connectors | 1 |
