Built-in processor | Yes |
Certification | CE-LVD: IEC 62368-1:2014
CE-EMC: EN IEC 61000-3-2:2019, EN 61000-3-3:2013+A1:2019, EN 55032:2015+A11:2020, EN 55035:2017+A11:2020, EN 55024:2010+A1:2015, EN 50130-4:2011+A1:2014 |
Rack capacity | 1U |
Product colour | Black |
Rack mounting | Yes |
Output current | 1.22 A |
Power consumption (max) | 25.5 W |
Power consumption (typical) | 36 W |
Output voltage | 53 V |
Operating relative humidity (H-H) | 10 - 93% |
Operating temperature (T-T) | -10 - 55 °C |
Storage temperature (T-T) | -20 - 60 °C |
Weight | 850 g |
PACKAGE WEIGHT | 1.85 kg |
Package height | 311 mm |
Package depth | 119 mm |
Width | 260 mm |
Height | 47.6 mm |
Package width | 374 mm |
Depth | 232.5 mm |
Mobile operating systems supported | iOS |
Browser supported | Chrome; IE; Safari; Edge; Firefox |
Supported resolutions | HDMI: 3840 × 2160, 1920 × 1080, 1280 × 1024, 1280 × 720
VGA: 1920 × 1080, 1280 × 1024, 1280 × 720 |
Video input channels | 4 channels |
Video recording modes | 720p |
Maximum Resolution | 3840 x 2160 pixels |
Video motion detection | Yes |
Input bandwidth | 80 Mbit/s |
Output bandwidth | 60 Mbit/s |
Video formats supported | H.265 |
Audio formats supported | G.726 |
Image formats supported | MJPEG |
Operating system installed | Embedded LINUX |
Wi-Fi | No |
Ethernet LAN data rates | 100 |
Audio RCA outputs | 1 |
USB 2.0 ports quantity | 2 |
VGA (D-Sub) output ports | 1 |
Networking standards | IEEE 802.3at |
Audio RCA inputs | 1 |
eSATA ports quantity | 1 |
Power Over Ethernet (PoE) | Yes |
Ethernet LAN (RJ-45) ports | 1 |
HDMI ports quantity | 1 |
Maximum storage capacity | 20 TB |
HDD interface | SATA |
Warnings | Do not expose the device to moisture or extreme temperatures. |
