| Built-in processor | Yes |
| Certification | CE-LVD: IEC 62368-1:2014
CE-EMC: EN IEC 61000-3-2:2019, EN 61000-3-3:2013+A1:2019, EN 55032:2015+A11:2020, EN 55035:2017+A11:2020, EN 55024:2010+A1:2015, EN 50130-4:2011+A1:2014 |
| Rack mounting | Yes |
| Product colour | Black |
| Rack capacity | 1U |
| Output current | 2 A |
| Power consumption (typical) | 10 W |
| Output voltage | 12 V |
| Operating temperature (T-T) | -10 - 55 °C |
| Operating relative humidity (H-H) | 10 - 93% |
| Storage temperature (T-T) | -20 - 60 °C |
| Width | 260 mm |
| Depth | 232.5 mm |
| Height | 47.6 mm |
| Weight | 810 g |
| Package height | 314 mm |
| Package depth | 89 mm |
| PACKAGE WEIGHT | 1.38 kg |
| Package width | 334 mm |
| Mobile operating systems supported | iOS |
| Browser supported | Chrome; IE; Safari; Edge; Firefox |
| Supported resolutions | HDMI: 3840 × 2160, 1920 × 1080, 1280 × 1024, 1280 × 720
VGA: 1920 × 1080, 1280 × 1024, 1280 × 720 |
| Image formats supported | MJPEG |
| Output bandwidth | 60 Mbit/s |
| Operating system installed | Embedded LINUX |
| Video recording modes | 1080p |
| Video formats supported | H.264+ |
| Audio formats supported | G.711 μ-law |
| Video motion detection | Yes |
| Video input channels | 16 channels |
| Face detection | Yes |
| Input bandwidth | 80 Mbit/s |
| Maximum Resolution | 3840 x 2160 pixels |
| Wi-Fi | No |
| Audio RCA inputs | 1 |
| Audio RCA outputs | 1 |
| VGA (D-Sub) output ports | 1 |
| Ethernet LAN data rates | 10 |
| USB 2.0 ports quantity | 2 |
| Ethernet LAN (RJ-45) ports | 1 |
| HDMI ports quantity | 1 |
| eSATA ports quantity | 1 |
| Maximum storage capacity | 20 TB |
| HDD interface | SATA |
