Certification | UL, CE, FCC |
Rack mounting | Yes |
Rack capacity | 1U |
Product colour | Black |
Power over Ethernet (PoE) power per port | 25.5 W |
AC input voltage | 100 - 240 V |
Power consumption (typical) | 15.6 W |
Total Power over Ethernet (PoE) budget | 130 W |
AC input frequency | 50 - 60 Hz |
Operating temperature (T-T) | -10 - 55 °C |
Storage temperature (T-T) | 0 - 40 °C |
Height | 53 mm |
Depth | 327.4 mm |
PACKAGE WEIGHT | 4 kg |
Weight | 2.7 kg |
Width | 375 mm |
Supported resolutions | 3840 x 2160
1920 x 1080
1280 x 1024
1280 x 720
1024 x 768 |
Recording Modes | Manual |
Face detection | Yes |
Video loss detection | Yes |
Operating system installed | Embedded LINUX |
Video input channels | 16 channels |
Video formats supported | M-JPEG |
Number of users | 128 user(s) |
Video motion detection | Yes |
Backup function | Yes |
Maximum Resolution | 3840 x 2160 pixels |
Multi-screen | Yes |
Alarm input channels | 4 |
Two-way talk | Yes |
Ethernet LAN data rates | 10 |
VGA (D-Sub) output ports | 1 |
Networking standards | IEEE 802.3at |
RS-232 interface | Yes |
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 1 |
RS-232 ports | 1 |
USB 2.0 ports quantity | 1 |
RS-485 ports | 1 |
Ethernet LAN (RJ-45) ports | 1 |
Power over Ethernet (PoE) ports quantity | 8 |
HDMI ports quantity | 1 |
Power Over Ethernet (PoE) | Yes |
Number of HDDs supported | 2 |
HDD interface | Serial ATA III |
