| Certification | CE EMC: EN 55032:2015+A1:2020; EN IEC 61000-3-2:2019+A1:2021; EN 61000-3-3:2013+A1:2019+A2:2021; EN 55035:2017+A11:2020; EN 50130-4:2011+A1:2014CE-LVD: EN 62368-1:2014EN 55032:2015, Class A, EN IEC 61000-3-2:2019, EN 61000-3-3:2013+A1:2019, EN 55024:2010+A1:2015;EN 55035:2017, EN 50130-4:2011+A1:2014 CE LVD: EN 62368-1:2014 FCC: 47 CFR FCC Part15, SubpartB, Class A 2023-02-15 |
| Product colour | White |
| Current | 2 A |
| DC output voltage | 12 |
| Power consumption (typical) | 10 W |
| Power source type | DC |
| Operating temperature (T-T) | -10 - 55 °C |
| Storage relative humidity (H-H) | 10 - 93% |
| Height | 96 mm |
| Weight | 450 g |
| Width | 364 mm |
| PACKAGE WEIGHT | 1.07 kg |
| Depth | 261 mm |
| Supported resolutions | 4608x3472, 3840x2160, 1920x1080, 1280x1024, 1280x720, 1920x1080, 1280x1024, 1280x720 |
| Video formats supported | H.264 |
| Video input channels | 4 channels |
| Video motion detection | Yes |
| People counting function | No |
| Total megapixels | 16 MP |
| Recording Modes | Motion detection, manual recording, smart recording, alarm |
| Backup function | Yes |
| Audio codecs | G.711a, G.711Mu, G.726, PCM |
| Playback Modes | Instant playback, general playback, event playback, smart playback |
| Maximum Resolution | 4608 x 3472 pixels |
| HDD interface | SATA |
| Maximum storage capacity | 16 TB |
| Ethernet LAN data rates | 10,100 Mbit/s |
| HDMI ports quantity | 1 |
| VGA (D-Sub) output ports | 1 |
| Power Over Ethernet (PoE) | No |
| USB 2.0 ports quantity | 2 |
| RCA input | 1 |
| Number of SATA connectors | 1 |
| Audio RCA outputs | 1 |
