Compliance certificates | Federal Communications Commission (FCC) |
Certification | EN IEC 61000-3-2:2019+A1:2021;
EN 61000-3-3:2013+A1:2019+A2:2021; EN
55035:2017+A11:2020; EN 50130-4:2011+A1:2014
CE-LVD: EN 62368-1:2014 |
Rack mounting | Yes |
Product colour | Black |
Rack capacity | 1U |
Power consumption (typical) | 25.5 W |
Power consumption (max) | 10 W |
Operating relative humidity (H-H) | 10 - 93% |
Storage temperature (T-T) | -20 - 60 °C |
Operating temperature (T-T) | -10 - 55 °C |
Package depth | 141 mm |
Package width | 433 mm |
Package height | 366 mm |
Depth | 284.3 mm |
Height | 53 mm |
Width | 375 mm |
PACKAGE WEIGHT | 2.76 kg |
Weight | 1.51 kg |
Mobile operating systems supported | Android |
Browser supported | Chrome; IE9 and later; Firefox |
Supported resolutions | HDMI: 3840 × 2160, 1920 × 1080, 1280 × 1024, 1280 × 720
VGA: 1920 × 1080, 1280 × 1024, 1280 × 720
*Simultaneous/heterogeneous video sources output for VGA and HDMI is configurable |
Video recording modes | 1080p |
Image formats supported | MJPEG |
Input bandwidth | 256 Mbit/s |
Alarm output channels | 2 |
Video input channels | 8 channels |
Alarm input channels | 4 |
Audio formats supported | G.711 A-law |
Video formats supported | H.265 |
Face detection | Yes |
Output bandwidth | 256 Mbit/s |
People counting | Yes |
Multi-screen | Yes |
Backup function | Yes |
Operating system installed | Embedded LINUX |
Maximum Resolution | 3840 x 2160 pixels |
Wi-Fi | No |
Audio RCA inputs | 1 |
VGA (D-Sub) output ports | 1 |
HDMI ports quantity | 1 |
HDMI output | Yes |
Audio RCA outputs | 1 |
Power Over Ethernet (PoE) | Yes |
Power over Ethernet (PoE) ports quantity | 8 |
Ethernet LAN (RJ-45) ports | 1 |
Networking standards | IEEE 802.3at |
USB 2.0 ports quantity | 2 |
DC-in jack | Yes |
Ethernet LAN data rates | 10 |
HDD interface | SATA |
Maximum storage capacity | 16 TB |
Number of HDDs supported | 2 |
