Compliance certificates | CB |
On/off switch | Yes |
Product colour | Black |
Rack mounting | Yes |
Rack capacity | 1.5U |
AC input voltage | 100 - 240 V |
Power consumption (typical) | 20 W |
Total Power over Ethernet (PoE) budget | 200 W |
AC input frequency | 50 - 60 Hz |
Operating temperature (T-T) | -10 - 55 °C |
Operating relative humidity (H-H) | 10 - 90% |
Height | 75 mm |
Depth | 400 mm |
Weight | 5 kg |
Width | 445 mm |
Video formats supported | H.265+ |
Number of simultaneously playbacked channels | 16 channels |
Languages support | Multi |
Audio formats supported | G.722 |
Video input channels | 16 channels |
Maximum Frame Rate | 30 fps |
Number of users | 128 user(s) |
Video motion detection | Yes |
Input bandwidth | 160 Mbit/s |
Face detection | Yes |
Audio system | 2-way |
Maximum Resolution | 3840 x 2160 pixels |
Output bandwidth | 160 Mbit/s |
Wi-Fi | No |
Audio RCA inputs | 1 |
Networking standards | IEEE 802.3at |
Ethernet LAN (RJ-45) ports | 1 |
USB 2.0 ports quantity | 2 |
RS-485 ports | 1 |
Supported network protocols | TCP/IP, DHCP, IPv4, IPv6, DNS, DDNS, NTP, RTSP, SADP, SMTP, SNMP, NFS, iSCSI, ISUP, UPnP, HTTP, HTTPS |
RS-232 interface | Yes |
HDMI output | Yes |
Audio RCA outputs | 1 |
Ethernet LAN data rates | 100 |
Power Over Ethernet (PoE) | Yes |
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 1 |
RS-232 ports | 1 |
Power over Ethernet (PoE) ports quantity | 16 |
VGA (D-Sub) output ports | 1 |
HDMI ports quantity | 1 |
HDD interface | SATA |
HDD Capacity | 0 GB |
Maximum storage capacity | 64 TB |
Number of HDDs supported | 4 |
Warnings | The product must be disposed of properly in accordance with local regulations for the disposal of electronics. |
