| Rack mounting | Yes |
| Rack capacity | 1U |
| Product colour | Black |
| Output voltage | 12 V |
| Power consumption (typical) | 10 W |
| Power | 18 W |
| Operating relative humidity (H-H) | 10 - 90% |
| Operating temperature (T-T) | -10 - 55 °C |
| Width | 260 mm |
| Height | 48 mm |
| Depth | 225 mm |
| Weight | 1 kg |
| Supported resolutions | 1920 × 1080, 1600 × 1200, 1280 × 1024, 1280 × 720, 1024 × 768 |
| Output bandwidth | 60 Mbit/s |
| Video codecs | H.265+/H.265/ H.264+/H.264 |
| Video input channels | 4 channels |
| Input bandwidth | 40 Mbit/s |
| Maximum Resolution | 1920 x 1080 pixels |
| Wi-Fi | No |
| HDMI output | Yes |
| VGA (D-Sub) output ports | 1 |
| DC-in jack | Yes |
| Ethernet LAN data rates | 100 |
| Supported network protocols | TCP/IP, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, SMTP,UPnP |
| USB 2.0 ports quantity | 2 |
| Ethernet LAN (RJ-45) ports | 1 |
| HDMI ports quantity | 1 |
| HDD Capacity | 0 GB |
| Maximum storage capacity | 6 TB |
| Number of HDDs supported | 1 |
| HDD interface | SATA II |
