Built-in processor | Yes |
Certification | CE-EMC: EN 55032:2015+A1:2020; EN IEC 61000-3-
2:2019+A1:2021; EN 61000-3-
3:2013+A1:2019+A2:2021; EN 55035:2017+A11:2020;
EN 50130-4:2011+A1:2014 CE-LVD: EN 62368-1:2014 |
Rack mounting | Yes |
Rack capacity | 1U |
Product colour | Black |
Output voltage | 12 V |
Output current | 2 A |
Power consumption (typical) | 10 W |
Operating temperature (T-T) | -10 - 55 °C |
Operating relative humidity (H-H) | 10 - 93% |
Storage temperature (T-T) | -20 - 60 °C |
Height | 47.6 mm |
Depth | 232.5 mm |
Width | 260 mm |
Weight | 810 g |
PACKAGE WEIGHT | 1.38 kg |
Package width | 334 mm |
Package depth | 89 mm |
Package height | 314 mm |
Browser supported | Chrome; IE; Safari; Edge; Firefox |
Mobile operating systems supported | iOS |
Supported resolutions | 1 HDMI, 1 VGA Simultaneous: HDMI: 3840 × 2160, 1920 × 1080, 1280 × 1024, 1280 × 720 VGA: 1920 × 1080, 1280 × 1024, 1280 × 720 Heterogeneous: HDMI: 1920 × 1080, 1280 × 1024, 1280 × 720 VGA: 1920 × 1080, 1280 × 1024, 1280 × 720 |
Audio formats supported | G.711 A-law |
Video recording modes | 960p |
Input bandwidth | 80 Mbit/s |
Output bandwidth | 60 Mbit/s |
Image formats supported | MJPEG |
Video formats supported | H.264+ |
Operating system installed | Embedded LINUX |
Face detection | Yes |
Video input channels | 4 channels |
Multi-screen | Yes |
Video motion detection | Yes |
Maximum Resolution | 3840 x 2160 pixels |
Wi-Fi | No |
Audio RCA inputs | 1 |
Audio RCA outputs | 1 |
VGA (D-Sub) output ports | 1 |
Ethernet LAN data rates | 10 |
USB 2.0 ports quantity | 2 |
HDMI ports quantity | 1 |
Power Over Ethernet (PoE) | Yes |
Ethernet LAN (RJ-45) ports | 1 |
eSATA ports quantity | 1 |
Maximum storage capacity | 20 TB |
Warnings | The product must be disposed of properly in accordance with local regulations for the disposal of electronics. |
