Channels 8 | Drives/bays 1 | Desktop/pedestal | Rack | CPU Embedded Linux | SATA | 1x15pin D-sub | 1xHDMI | 1xAudio-In | 1xAudio-Out | 2xUSB 2.0 | 1xRJ45 | Power supply requirements 12 VDC, 1.5 A | Power consumption 10 Watts | Dim. 204.6 × 206.4 × 45.6 mm | Temp. range –10 °C to +55 °C
Description | 8 IP channel max, up to 12MP resolution
80Mbps record rate
VGA/HDMI up to 1-channel 12MP @30 fps; 6-channel 1080p @ 30 fps
1 SATA port, up to 16 TB 3.5” HDD, 10/100M LAN
No front panel control, no Alarm I/O, 2 USB
Smart 1U case (white), mouse included
ONVIF (profile T/S/G); CGI; SDK
Connected to the third-party network cameras
4-channel SMD Plus (AI by camera), secondary filtering for human and motor vehicle SMD Plus
Free IP monitoring software available
|
Vendor Homepage | www.dahuasecurity.com/products/All-Products/Network-Recorders/Lite-Series/NVR2-S3-Series/1HDD/NVR2108-S3 |
Model | DHI-NVR2108-S3 |
Number of channels | 8 |
Number of drives/bays | 1 |
Desktop/pedestal | Yes |
Rack | Yes |
CPU | Embedded Linux |
SATA | Yes |
15pin D-sub | 1 |
Audio-In | 1 |
Audio-Out | 1 |
HDMI | 1 |
RJ45 | 1 |
USB 2.0 | 2 |
Power supply requirements | 12 VDC, 1.5 A |
Power consumption | 10 Watts |
Dimensions | 204.6 × 206.4 × 45.6 mm |
Operating temperature range | –10 °C to +55 °C |
Unit Net Weight | 0.42 kg |
Unit Gross Weight | 0.99 kg |
Unit Box Width | 0.265 |
Unit Box Length | 0.365 |
Unit Box Height | 0.095 |
Full Description Line | Channels 8|Drives/bays 1|Desktop/pedestal|Rack|CPU Embedded Linux|SATA|1x15pin D-sub|1xHDMI|1xAudio-In|1xAudio-Out|2xUSB 2.0|1xRJ45|Power supply requirements 12 VDC, 1.5 A|Power consumption 10 Watts|Dim. 204.6 × 206.4 × 45.6 mm|Temp. range –10 °C to +55 °C |
Category Code | NVR |
