| Certification | CE/FCC |
| Product colour | Black |
| Power over Ethernet (PoE) power per port | 25.5 W |
| Current | 1.25 A |
| DC output voltage | 48 |
| Power consumption (Power over Ethernet (PoE)) | 36 W |
| Power consumption (typical) | 10 W |
| Power source type | DC, PoE |
| Storage relative humidity (H-H) | 10 - 93% |
| Operating temperature (T-T) | -10 - 45 °C |
| Storage temperature (T-T) | 0 - 40 °C |
| Width | 260 mm |
| Depth | 225 mm |
| Height | 47.5 mm |
| Weight | 840 g |
| PACKAGE WEIGHT | 1.86 kg |
| Backup function | Yes |
| Recording Modes | Motion detection, manual recording, smart recording, alarm |
| Total megapixels | 8 MP |
| Audio codecs | G.711a, G.711Mu, G.726, PCM |
| Video input channels | 4 channels |
| Video formats supported | H.265 |
| Playback Modes | Play |
| Video motion detection | Yes |
| People counting function | No |
| HDD interface | SATA II |
| Maximum storage capacity | 8 TB |
| HDMI ports quantity | 1 |
| Power Over Ethernet (PoE) | Yes |
| Number of SATA connectors | 1 |
| Audio RCA outputs | 1 |
| Ethernet LAN data rates | 10,100 Mbit/s |
| USB 2.0 ports quantity | 2 |
| RCA input | 1 |
| Power over Ethernet (PoE) ports quantity | 4 |
| Ethernet LAN (RJ-45) ports | 1 |
| VGA (D-Sub) output ports | 1 |
