| Product colour | Black |
| Output voltage | 48 - 53 V |
| Power over Ethernet (PoE) power per port | 25 W |
| Power consumption (typical) | 10 W |
| Operating relative humidity (H-H) | 10 - 90% |
| Operating temperature (T-T) | -10 - 45 °C |
| Weight | 1.4 kg |
| Height | 41 mm |
| Depth | 230 mm |
| Width | 260 mm |
| Mobile operating systems supported | Android |
| Mac compatibility | Yes |
| Browser supported | Edge, Firefox, Chrome, Safari |
| Windows operating systems supported | Yes |
| Supported resolutions | 3840x2160, 1920x1080, 1280x1024, 1280x720, 1024x768 |
| Number of users | 20 user(s) |
| Number of simultaneously playbacked channels | 4 channels |
| Video formats supported | H.264 |
| Maximum Resolution | 3840 x 2160 pixels |
| Video recording modes | 1080p |
| Video motion detection | Yes |
| Video input channels | 8 channels |
| Wi-Fi | No |
| USB 2.0 ports quantity | 2 |
| Ethernet LAN data rates | 10 |
| Networking standards | IEEE 802.3af |
| eSATA | Yes |
| Power Over Ethernet (PoE) | Yes |
| VGA (D-Sub) output ports | 1 |
| Power over Ethernet (PoE) ports quantity | 8 |
| Ethernet LAN (RJ-45) ports | 9 |
| Supported network protocols | HTTPS, TCP/IP, UDP, DHCP, P2P, UPNP, RTMP, SMTP, SSL/TLS, DNS, DDNS, NTP |
| HDMI output | Yes |
| Audio RCA outputs | 1 |
| Ethernet WAN | Yes |
| HDMI ports quantity | 1 |
| Maximum storage capacity | 12 TB |
| Number of HDDs supported | 2 |
| HDD interface | eSATA |
