Rack mounting | Yes |
LED indicators | LAN |
Product colour | Black |
Total Power over Ethernet (PoE) budget | 53 W |
Output voltage | 53.5 V |
Power consumption (max) | 12.94 W |
Output current | 1.31 A |
Operating temperature (T-T) | -10 - 55 °C |
Width | 294 mm |
Height | 44 mm |
Depth | 180 mm |
Package Type | Box |
Supported resolutions | 1920 x 1080, 1680 x 1050, 1440 x 900, 1280 x 1024,
102 4x 768, 1280 x 720 |
Video formats supported | H.264 |
Maximum Resolution | 3840 x 2160 pixels |
Audio system | 2-way |
Video input channels | 8 channels |
Output bandwidth | 60 Mbit/s |
Video recording modes | 720p |
Input bandwidth | 80 Mbit/s |
Number of simultaneously playbacked channels | 8 channels |
Quick installation guide | Yes |
AC adapter included | Yes |
Networking standards | IEEE 802.3af |
Supported network protocols | TCP/IP, DHCP, DNS, NTP, UPnP |
Ethernet LAN data rates | 100 |
Ethernet LAN (RJ-45) ports | 1 |
HDMI ports quantity | 1 |
Power Over Ethernet (PoE) | Yes |
Power over Ethernet (PoE) ports quantity | 8 |
USB 2.0 ports quantity | 2 |
DC-in jack | Yes |
Audio RCA outputs | 1 |
VGA (D-Sub) output ports | 1 |
Audio RCA inputs | 1 |
HDD interface | SATA |
Number of HDDs supported | 1 |
Maximum storage capacity | 10 TB |
HDD Capacity | 0 GB |
