Processor model | Quectel EG18 |
Internal memory type | DDR3 |
Flash Memory | 16 MB |
INTERNAL MEMORY | 256 MB |
Processor cores | 2 |
LED indicators | Power, Status |
Product Type | Tabletop router |
Product colour | Black |
Output voltage | 12 V |
Power source type | AC, DC |
AC input voltage | 90 - 260 V |
Output current | 1.5 A |
DMZ support | Yes |
MAC address filtering | Yes |
IP address filtering | Yes |
Firewall | Yes |
Schedule access | Yes |
Storage temperature (T-T) | -40 - 70 °C |
Operating relative humidity (H-H) | 5 - 95% |
Operating temperature (T-T) | 0 - 45 °C |
DESPITE | Yes |
Quality of Service (QoS) support | Yes |
Reset button | Yes |
WPS push button | Yes |
Height | 48.2 mm |
Depth | 253 mm |
Width | 152.5 mm |
VPN support | PPTP/L2TP/OpenVPN/WireGuard/IPsec/Zerotier |
Ethernet LAN interface type | Gigabit Ethernet |
Dynamic DNS (DDNS) | Yes |
Ethernet LAN | Yes |
Port triggering | Yes |
Port forwarding | Yes |
Windows operating systems supported | Windows 8 |
Minimum RAM | 256 MB |
Mac operating systems supported | MacOS |
Mac compatibility | Yes |
Browser supported | Firefox 12.0, Chrome 20.0, Safari 4.0 |
Number of products included | 1 pc(s) |
Package Type | Box |
Package width | 265 mm |
Package depth | 415 mm |
Package height | 90 mm |
CABLES INCLUDED | LAN (RJ-45) |
Quick installation guide | Yes |
Wi-Fi band | Dual-band (2.4 GHz / 5 GHz) |
WLAN data transfer rate (max) | 1201 Mbit/s |
WLAN data transfer rate (first band) | 574 Mbit/s |
Wi-Fi standards | 802.11g |
Top Wi-Fi standard | Wi-Fi 6 (802.11ax) |
DHCP Server | Yes |
Universal Plug and Play (UPnP) | Yes |
DHCP client | Yes |
DC-in jack | Yes |
USB Port | No |
Ethernet LAN (RJ-45) ports | 4 |
Antenna Connector Type | SMA |
Antennas quantity | 6 |
Antenna design | External |
WAN connection type | RJ-45 |
Ethernet WAN | Yes |
SIM card slot | Yes |
3G/4G USB modem compatibility | Yes |
4G standard | LTE-TDD & LTE-FDD |
3G standards | WCDMA |
Mobile network generation | 4G |
Dual SIM support | Yes |
Short Message Service (SMS) | Yes |
SIM Card Type | NanoSIM |
