| Mudeli versioon |
P2 1.0 |
| CPU |
CPU Details |
1.3 GHz Dual-Core, ARM Cortex-A53 |
| Memory/Storage |
Flash/ROM |
128 MB (1 Gbit) NAND |
| |
DDR/RAM |
256 MB (2 Gbit) DDR3 |
| Cellular |
Cellular Standards |
- 5G Rel. 15
- DL 4G Cat. 12/ UL 4G Cat. 13
|
| |
Cellular Antennas |
4× Internal, 2× SMA Connectors for Customized Antennas |
| |
Detachable Cellular Antennas Connector |
SMA Female |
| |
SIM Options |
- 1× Nano SIM Slot
- eSIM (Optional for ISP Orders)
|
| |
Available Versions |
EU |
| EU Version Cellular |
Suitable Region |
Europe, Middle East, Africa, Asia-Pacific, Latin America |
| |
Max DL Speed |
2.6 Gbps (NSA), 2 Gbps (SA) |
| |
Max UL Speed |
650 Mbps (NSA), 1 Gbps (SA) |
| |
Advanced |
5G+4G Dual Connectivity, DL 4×4, UL 2×2 MIMO |
| |
Cellular Bands |
5G Sub 6 GHz: n1/3/5/7/8/20/28/38/40/41/66/77/78
LTE-FDD: B1/2/3/4/5/7/8/20/28/38/40/41/66
WCDMA: B1/2/5/8 |
| Wireless |
5 GHz Wi-Fi Speed |
2402 Mbps |
| |
2.4 GHz Wi-Fi Speed |
574 Mbps |
| |
5 GHz Wi-Fi Streams |
2T2R (2×2 MIMO) |
| |
2.4 GHz Wi-Fi Streams |
2T2R (2×2 MIMO) |
| |
Wi-Fi Antennas |
Internal |
| |
Beamforming |
True |
| |
FEM or PA/LNA |
- 5 GHz: 3× Internal
- 2.4 GHz: 2× Internal
|
| |
Range Performance |
Max: 170 m (558 ft)
Tested in open-space environments with minimal interference. Actual WiFi range may vary depending on layout and wall materials. Refer to the Wall Performance specifications for placement suggestions. |
| |
Wall Performance |
Two wooden walls with thickness < 10 cm (4'')
One concrete wall with thickness < 20 cm (7'') |
| Interfaces |
Physical Buttons |
|
| |
Gigabit RJ45 Ports |
2 |
| |
Ethernet Notes |
1× RJ45 port is WAN/LAN configurable, and the rest are LAN ports |
| |
FXS Ports |
1× RJ11 (VoNR/VoLTE) (Optional) |
| |
LED |
- Power
- Internet
- Wi-Fi
- Cellular
|
| |
Power Input |
DC Jack |
| Power |
Power Methods |
DC |
| |
DC Input |
12V 1.5A |
| |
Power Adapter |
Input: 100 ~ 240 V, 50/60 Hz AC
Output: 12V 1.5A DC |
| Reliability |
EMC |
ESD: Contact: 4kV; Air: 8kV |
| |
Environment |
Operating Temperature: 0 ℃ ~ 40 ℃ (32 ℉ ~104 ℉)
Storage Temperature: -40 ℃ ~ 70 ℃ (-40 ℉ ~ 158 ℉)
Operating Humidity: 10% ~ 90% non-condensing
Storage Humidity: 5% ~ 90% non-condensing |
| Certifications |
FCC, CE |
| Mechanical |
Dimension |
Φ116×202 mm
Φ4.57×7.95 inches |
| |
Product Weight |
650.8 g (22.96 oz.) |
| |
Installation |
Desktop |
| Package Content |
- P2
- Power Adapter
- Ethernet Cable
- Installation Guide
|
| Ordering Information |
Retail Package Weight |
EU: 1082.5 g (38.18 oz.) |
| |
Retail Package Dimension |
1-Pack:
313×152×132 mm
12.32×5.98×5.2 inches |
| |
Units per Carton |
1-Pack: 8 |
| |
Carton Net Weight |
EU: 8.7 kg (19.18 lbs) |
| |
Carton Gross Weight |
EU: 9.5 kg (20.94 lbs) |
| |
Carton Dimension |
1-Pack: 55.4×32.1×33.2 cm
21.81×12.64×13.07 inches |
