| LED indicators | LAN, Power, Status, WLAN |
| Product colour | Black |
| On/off switch | Yes |
| Product Type | Tabletop router |
| Wall mountable | Yes |
| Power source type | DC |
| Output current | 1.5 A |
| Output voltage | 12 V |
| Security algorithms | WPA2-PSK |
| Stateful Packet Inspection (SPI) | Yes |
| Firewall security | DoS, SPI Firewall, IP and MAC Address Binding |
| Access Control List (ACL) | Yes |
| Guest access | Yes |
| DoS attack prevention | Yes |
| Firewall | Yes |
| DMZ support | Yes |
| Storage temperature (T-T) | -40 - 70 °C |
| Operating temperature (T-T) | 0 - 40 °C |
| Operating relative humidity (H-H) | 10 - 90% |
| Storage relative humidity (H-H) | 5 - 90% |
| Reset button | Yes |
| Web-based management | Yes |
| Quality of Service (QoS) support | Yes |
| WPS push button | Yes |
| Height | 33.5 mm |
| Depth | 124.5 mm |
| Width | 174 mm |
| VPN support | PPTP, L2TP, IPSec |
| Receiver sensitivity | 5GHz: 11a 54M: -74dBm
11ac HT20: -67dBm
11ac HT40: -64dBm
11ac HT80 : -60dBm
11n HT20: -71dBm
11n HT40: -70dBm
2.4G: 11g 54M: -76dBm
11n HT20: -73dBm
11n HT40: -67dBm |
| Ethernet LAN data rates | 100 |
| Networking standards | IEEE 802.11a |
| Ethernet LAN interface type | Fast Ethernet |
| Cabling technology | 10/100Base-T(X) |
| VPN tunnels quantity | 10 |
| Ethernet LAN | Yes |
| Port forwarding | Yes |
| VPN Passthrough | Yes |
| Dynamic DNS (DDNS) | Yes |
| VPN server | PPTP VPN, IPSec VPN , OpenVPN |
| Mac operating systems supported | MacOS |
| Windows operating systems supported | Windows XP Home x64 |
| Mac compatibility | Yes |
| Linux operating systems supported | Yes |
| Package height | 70 mm |
| Package Type | Box |
| Package depth | 223 mm |
| Package width | 307 mm |
| PACKAGE WEIGHT | 670 g |
| AC adapter included | Yes |
| Quick installation guide | Yes |
| CABLES INCLUDED | LAN (RJ-45) |
| Wi-Fi standards | Wi-Fi 4 (802.11n) |
| Wi-Fi band | Dual-band (2.4 GHz / 5 GHz) |
| WLAN data transfer rate (max) | 867 Mbit/s |
| Top Wi-Fi standard | Wi-Fi 5 (802.11ac) |
| WLAN data transfer rate (second band) | 867 Mbit/s |
| WLAN data transfer rate (first band) | 450 Mbit/s |
| DHCP client | Yes |
| Universal Plug and Play (UPnP) | Yes |
| Supported network protocols | IPv4, IPv6 |
| DHCP Server | Yes |
| Ethernet LAN (RJ-45) ports | 3 |
| DC-in jack | Yes |
| USB Port | No |
| Memory card slot(s) | No |
| Antennas quantity | 2 |
| Detachable antenna(s) | Yes |
| Transmit power | CE: <20dBm(2.4GHz), <23dBm(5GHz) |
| Antenna design | Internal & external |
| Ethernet WAN | Yes |
| DSL WAN | No |
| SIM card slot | Yes |
| WAN connection type | RJ-45 |
| 3G/4G USB modem compatibility | No |
| Harmonized System (HS) code | 85176990 |
| 3G | Yes |
| 4G | Yes |
| 2G standards | Edge |
| 3G standards | DC-HSPA+ |
| 4G bands supported | 2100 |
| SIM Card Type | MicroSIM |
| GSM bands supported | 850 |
| UMTS bands supported | 2100 MHz |
| Mobile network generation | 4G |
| 4G standard | LTE |
| Warnings | Do not expose the device to extreme temperatures. |
