storage medium | |
storage capacity | 32 GB |
Supported storage drive interfaces | SATA |
supported storage drive sizes | 2.5,3.5" |
Eigenschaft | Nachhaltigkeitskonformität |
RAID Level | 0, 1, 5, 6, 10, F1, JBOD |
Supported file systems | BTRFS, Fett, HFS+, NTFS, exFAT, ext3, ext4 |
Total installed storage capacity | 0 TB |
Number of supported storage drives | 12 |
Supported storage drives | HDD & SSD |
processor | 7272 |
processor manufacturer | AMD |
processor family | EPYC |
processor clock speed | 2,9 GHz |
Processor Boost Frequency | 3,2 GHz |
number of CPU cores | 12 |
processor threads | 24 |
Buffer memory L3 | 64 MB |
Storage | |
Internal storage type | DDR4 |
Maximum supported RAM | 1,02 TB |
memory card slots | 16 |
Memory form factor | RDIMM |
network | |
Ethernet LAN data transfer rates | 10,100,1000,10000 Mbit/s |
Supported Ethernet LAN data rate (max.) | 10000 Mbit/s |
Supported network protocols | SMB1 (CIFS), SMB2, SMB3, NFSv3, NFSv4, NFSv4.1, NFS Kerberized sessions, iSCSI, Fibre Channel, HTTP, HTTPs, FTP, SNMP, LDAP, CalDAV |
connections and interfaces | |
USB 3.2 Gen 1 (3.1 Gen 1) Number of Type A ports | 2 |
Number of Ethernet LAN ports (RJ-45) | 7 |
Simultaneous Connections | 8000 |
PCI Express x8 (Gen 3.x) connectors | 2 |
Design | |
case type | Rack (2U) |
cooling | Aktiv |
Product color | Schwarz |
number of fans | 4 Lüfter |
fan diameter | 8 cm |
LED indicators | Alarm, HDD, Leistung, Status |
Services | |
Type | NAS |
device class | Großunternehmen |
backup functions | Cloud, iSCSI LUN |
number of users | 16000 Benutzer |
Supported security algorithms | AES |
Supported browser | Google Chrome, Firefox, Microsoft Edge, Safari |
Shared Folder | SMB/AFP/NFS/FTP/WebDAV |
Software | |
Installed operating system | DiskStation Manager |
energy | |
Power supply placement | Eingebaut |
capacity of the power supply unit | 550 W |
Power consumption (standard operation) | 180,5 W |
Power consumption (HDD standby) | 88,56 W |
AC input voltage | 100 - 240 V |
AC input frequency | 50/60 Hz |
weight and dimensions | |
broad | 482 mm |
depth | 724 mm |
height | 88 mm |
Weight | 16,5 kg |
scope of delivery | |
Supplied cables | AC |
Anzahl Stromkabel | 2 |
sustainability | |
sustainability certificates | UL ECOLOGO |
operating conditions | |
operating temperatur | 0 - 35 °C |
Operating relative humidity | 8 - 80% |
Storage temperature range | -20 - 60 °C |
humidity during storage | 5 - 95% |
operating height | 0 - 5000 m |
Other functions | |
Konformitätsbescheinigungen | BSMI, CCC, CE, EAC, Eidgenössische Kommunikationskommission (FCC), KC, RoHS, UKCA |
