storage medium | |
Supported storage drive interfaces | Serial ATA II, Serial ATA III |
supported storage drive sizes | 2.5,3.5,M.2 |
Number of M.2 (M & B) slots | 2 |
Eigenschaft | Nachhaltigkeitskonformität |
RAID Level | 0, 1, JBOD |
RAID-Levels (Erweiterungseinheit) | 5, 6, 10 |
Supported file systems | BTRFS, Fett, HFS+, NTFS, exFAT, ext3, ext4 |
Number of supported storage drives | 2 |
Supported storage drives | HDD & SSD |
processor | R1600 |
processor manufacturer | AMD |
processor family | AMD Ryzen |
processor clock speed | 2,6 GHz |
Processor Boost Frequency | 3,1 GHz |
number of CPU cores | 2 |
Number of processors supported | 1 |
Storage | |
storage capacity | 2 GB |
Internal storage type | DDR4 |
Maximum supported RAM | 32 GB |
memory card slots | 2 |
Memory form factor | SO-DIMM |
network | |
Ethernet LAN data transfer rates | 10,100,1000 Mbit/s |
Supported Ethernet LAN data rate (max.) | 10000 Mbit/s |
Copper Ethernet cabling technology | 10BASE-T, 100BASE-TX, 1000BASE-T |
Supported network protocols | SMB1 (CIFS), SMB2, SMB3, NFSv3, NFSv4, NFSv4.1, NFS Kerberized sessions, iSCSI, HTTP, HTTPs, FTP, SNMP, LDAP, CalDAV |
connections and interfaces | |
USB 3.2 Gen 1 (3.1 Gen 1) Number of Type A ports | 1 |
Number of eSATA ports | 1 |
Number of Ethernet LAN ports (RJ-45) | 2 |
Simultaneous Connections | 500 |
PCI Express x2 slots (Gen 3.x) | 1 |
Design | |
case type | Tower |
cooling | Aktiv |
Product color | Schwarz |
number of fans | 1 Lüfter |
fan diameter | 9,2 cm |
Lock-Type Cable Barrier | Kensington |
Services | |
Type | NAS |
device class | Home & Home Office |
backup functions | Cloud, iSCSI LUN |
noise level | 20,7 dB |
Video input channels | 2 Kanäle |
management logs | SNMP |
Supported security algorithms | AES, HTTPS, SSH, SSL/TLS |
Supported browser | Google Chrome, Firefox, Microsoft Edge, Safari |
Software | |
Installed operating system | DiskStation Manager |
version of the operating system | 7,1,1 |
Supported server operating systems | Windows Server 2016, Windows Server 2019 |
energy | |
Power supply placement | Extern |
capacity of the power supply unit | 65 W |
Number of power supply units | 1 |
Power consumption (standard operation) | 21,07 W |
Power consumption (HDD standby) | 8,62 W |
AC input voltage | 100 - 240 V |
AC input frequency | 50 / 60 Hz |
weight and dimensions | |
broad | 106 mm |
depth | 223 mm |
height | 166 mm |
Weight | 1,51 kg |
scope of delivery | |
Supplied cables | AC, LAN (RJ-45) |
Anzahl Stromkabel | 1 |
sustainability | |
operating conditions | |
operating temperatur | 0 - 40 °C |
Operating relative humidity | 5 - 95% |
Storage temperature range | -20 - 60 °C |
humidity during storage | 5 - 95% |
Other functions | |
Konformitätsbescheinigungen | CE, RoHS |
certification | FCCBSMIVCCIRCMUKCAEACCCCKC |
