storage medium | |
Supported storage drive interfaces | Serial ATA II, Serial ATA III |
supported storage drive sizes | 2.5,3.5,M.2 |
Number of M.2 (M & B) slots | 2 |
Eigenschaft | Intel® VT-x mit Extended Page Tables (EPT) |
RAID Level | 0, 1, JBOD |
Supported file systems | FAT32, HFS+, NTFS, exFAT, ext3, ext4 |
Number of supported storage drives | 3 |
Supported storage drives | HDD & SSD |
processor | N5095 |
processor manufacturer | Intel |
processor family | Intel® Celeron® |
processor clock speed | 2 GHz |
Processor Boost Frequency | 2,9 GHz |
number of CPU cores | 4 |
processor threads | 4 |
CPU configuration (max) | 1 |
Eingebautes Grafikkartenmodell | Intel® UHD Graphics |
Storage | |
storage capacity | 8 GB |
Maximum supported RAM | 8 GB |
Flash memory | 5000 MB |
network | |
Ethernet LAN data transfer rates | 100,1000,2500 Mbit/s |
connections and interfaces | |
USB 3.2 Gen 1 (3.1 Gen 1) Number of Type A ports | 1 |
USB 3.2 Gen 2 (3.1 Gen 2) Number of Type A ports | 2 |
Number of HDMI ports | 1 |
HDMI-Version | 1.4b |
Number of Ethernet LAN ports (RJ-45) | 1 |
Simultaneous Connections | 1500 |
Design | |
case type | Tower |
cooling | Aktiv |
Product color | Weiß |
number of fans | 1 Lüfter |
fan diameter | 9,2 cm |
LED indicators | HDD, LAN, M.2, Status, System, USB |
Lock-Type Cable Barrier | Kensington |
Services | |
Type | NAS |
device class | Home & Home Office |
backup functions | Cloud, USB-Stick, iSCSI LUN |
number of users | 4096 Benutzer |
management logs | SNMP V2/V3 |
Supported security algorithms | 256-bit AES, FIPS 140-2, HTTPS, SSH, TLS |
Supported browser | Apple Safari, Google Chrome, Microsoft Edge, Mozilla Firefox |
Shared Folder | CIFS/SMB, AFP, NFS, FTP |
Software | |
Installed operating system | QNAP Turbo System |
version of the operating system | 5,0,1 |
Supports Windows operating systems | Windows 10, Windows 11, Windows 7, Windows 8 |
Supported server operating systems | Windows Server 2008 R2, Windows Server 2012, Windows Server 2012 R2, Windows Server 2016, Windows Server 2019 |
energy | |
Power supply placement | Extern |
capacity of the power supply unit | 65 W |
Number of power supply units | 1 |
Power consumption (standard operation) | 32,8 W |
Power consumption (HDD standby) | 18,9 W |
AC input voltage | 100 - 240 V |
fans voltage | 12 V |
weight and dimensions | |
broad | 150 mm |
depth | 260 mm |
height | 142 mm |
Weight | 1,64 kg |
scope of delivery | |
Supplied cables | AC, LAN (RJ-45) |
Anzahl Stromkabel | 1 |
Processor specifics | |
operating conditions | |
operating temperatur | 0 - 40 °C |
Operating relative humidity | 5 - 95% |
Storage temperature range | -20 - 70 °C |
humidity during storage | 5 - 95% |
