| storage medium | |
| storage capacity | 4 GB |
| storage drive interface | M.2, SATA |
| Supported storage drive interfaces | M.2, SATA |
| supported storage drive sizes | 2.5,3.5,M.2 |
| Maximum supported storage capacity | 180 TB |
| Number of M.2 (M & B) slots | 2 |
| Eigenschaft | Externes Netzteil |
| RAID Level | 0, 1, 5, 6, 10, JBOD |
| Supported file systems | BTRFS, FAT32, HFS+, NTFS, exFAT, ext3, ext4 |
| Total installed storage capacity | 0 TB |
| Number of supported storage drives | 9 |
| Supported storage drives | HDD & SSD |
| processor | V1500B |
| processor manufacturer | AMD |
| processor generation | AMD Ryzen Embedded V1000 Series |
| processor family | Ryzen Embedded |
| processor clock speed | 2,2 GHz |
| number of CPU cores | 4 |
| processor threads | 8 |
| Storage | |
| Internal storage type | DDR4 |
| Maximum supported RAM | 32 GB |
| memory card slots | 2 |
| Memory form factor | SO-DIMM |
| network | |
| Ethernet LAN data transfer rates | 2500 Mbit/s |
| Supported network protocols | SMB1 (CIFS), SMB2, SMB3, NFSv3, NFSv4, NFSv4.1, NFS Kerberized sessions, iSCSI, HTTP, HTTPs, FTP, SNMP, LDAP, CalDAV |
| connections and interfaces | |
| USB 3.2 Gen 1 (3.1 Gen 1) Number of Type A ports | 2 |
| Number of Ethernet LAN ports (RJ-45) | 2 |
| Design | |
| cooling | Aktiv |
| Product color | Schwarz |
| number of fans | 2 Lüfter |
| fan diameter | 9,2 cm |
| Diameter fan 2 | 9,2 cm |
| Services | |
| Type | NAS |
| device class | Home & Home Office |
| backup functions | Cloud, iSCSI LUN |
| number of users | 512 Benutzer |
| noise level | 20,5 dB |
| Supported browser | Chrome,Firefox,Edge,Safari |
| energy | |
| Power supply placement | Extern |
| capacity of the power supply unit | 100 W |
| Power consumption (standard operation) | 37,91 W |
| Power consumption (HDD standby) | 12,33 W |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50 - 60 Hz |
| weight and dimensions | |
| broad | 199 mm |
| depth | 223 mm |
| height | 166 mm |
| Weight | 2,26 kg |
| scope of delivery | |
| Supplied cables | AC, LAN (RJ-45) |
| Anzahl Stromkabel | 1 |
| operating conditions | |
| operating temperatur | 0 - 40 °C |
| Operating relative humidity | 5 - 95% |
| Storage temperature range | -20 - 60 °C |
| humidity during storage | 5 - 95% |
| Other functions | |
| Garantiezeit | 3 Jahr(e) |
| Konformitätsbescheinigungen | RoHS |
| certification | FCCCEBSMIVCCIRCMUKCAEACCCCKCBIS |
