storage medium | |
storage capacity | 4 GB |
storage drive interface | M.2, SATA |
Supported storage drive interfaces | M.2, SATA |
supported storage drive sizes | 2.5,3.5,M.2 |
Maximum supported storage capacity | 180 TB |
Number of M.2 (M & B) slots | 2 |
Eigenschaft | Externes Netzteil |
RAID Level | 0, 1, 5, 6, 10, JBOD |
Supported file systems | BTRFS, FAT32, HFS+, NTFS, exFAT, ext3, ext4 |
Total installed storage capacity | 0 TB |
Number of supported storage drives | 9 |
Supported storage drives | HDD & SSD |
processor | V1500B |
processor manufacturer | AMD |
processor generation | AMD Ryzen Embedded V1000 Series |
processor family | Ryzen Embedded |
processor clock speed | 2,2 GHz |
number of CPU cores | 4 |
processor threads | 8 |
Storage | |
Internal storage type | DDR4 |
Maximum supported RAM | 32 GB |
memory card slots | 2 |
Memory form factor | SO-DIMM |
network | |
Ethernet LAN data transfer rates | 2500 Mbit/s |
Supported network protocols | SMB1 (CIFS), SMB2, SMB3, NFSv3, NFSv4, NFSv4.1, NFS Kerberized sessions, iSCSI, HTTP, HTTPs, FTP, SNMP, LDAP, CalDAV |
connections and interfaces | |
USB 3.2 Gen 1 (3.1 Gen 1) Number of Type A ports | 2 |
Number of Ethernet LAN ports (RJ-45) | 2 |
Design | |
cooling | Aktiv |
Product color | Schwarz |
number of fans | 2 Lüfter |
fan diameter | 9,2 cm |
Diameter fan 2 | 9,2 cm |
Services | |
Type | NAS |
device class | Home & Home Office |
backup functions | Cloud, iSCSI LUN |
number of users | 512 Benutzer |
noise level | 20,5 dB |
Supported browser | Chrome,Firefox,Edge,Safari |
energy | |
Power supply placement | Extern |
capacity of the power supply unit | 100 W |
Power consumption (standard operation) | 37,91 W |
Power consumption (HDD standby) | 12,33 W |
AC input voltage | 100 - 240 V |
AC input frequency | 50 - 60 Hz |
weight and dimensions | |
broad | 199 mm |
depth | 223 mm |
height | 166 mm |
Weight | 2,26 kg |
scope of delivery | |
Supplied cables | AC, LAN (RJ-45) |
Anzahl Stromkabel | 1 |
operating conditions | |
operating temperatur | 0 - 40 °C |
Operating relative humidity | 5 - 95% |
Storage temperature range | -20 - 60 °C |
humidity during storage | 5 - 95% |
Other functions | |
Garantiezeit | 3 Jahr(e) |
Konformitätsbescheinigungen | RoHS |
certification | FCCCEBSMIVCCIRCMUKCAEACCCCKCBIS |
