storage medium | |
storage drive interface | Serial ATA III |
Supported storage drive interfaces | Serial ATA II, Serial ATA III |
supported storage drive sizes | 2.5,3.5" |
Eigenschaft | USB-Kopie-Funktion |
RAID Level | 0, 1, 5+S, 5, 6, 6+HS, 10+HS, 10, 50, 60, JBOD |
Supported file systems | FAT32, HFS+, ext3, ext4 |
Number of supported storage drives | 8 |
Supported storage drives | HDD & SSD |
processor | AL324 |
processor manufacturer | Annapurna Labs |
processor family | Annapurna Labs |
processor clock speed | 1,7 GHz |
number of CPU cores | 4 |
processor architecture | ARM Cortex-A57 |
Number of processors supported | 1 |
Storage | |
storage capacity | 4 GB |
Internal storage type | DDR4 |
memory clock speed | 2400 MHz |
Maximum supported RAM | 16 GB |
memory card slots | 1 |
Memory form factor | SO-DIMM |
Flash memory | 512 MB |
network | |
Ethernet LAN data transfer rates | 100,1000,2500,10000 Mbit/s |
connections and interfaces | |
USB 3.2 Gen 1 (3.1 Gen 1) Number of Type A ports | 3 |
Number of fiber connectors | 2 |
Optical cable connector | SFP+ |
Number of Ethernet LAN ports (RJ-45) | 2 |
Design | |
case type | Tower |
cooling | Aktiv |
Product color | Aluminium, Schwarz |
number of fans | 3 Lüfter |
fan diameter | 12 cm |
Diameter fan 2 | 6 cm |
LED indicators | HDD, LAN, Status, System, USB |
Lock-Type Cable Barrier | Kensington |
Services | |
Type | NAS |
device class | Kleines & Mittleres Unternehmen |
backup functions | Cloud, USB-Stick, iSCSI LUN |
noise level | 19,6 dB |
management logs | SNMP |
Remote-Management | 256-bit AES,FIPS 140-2,HTTPS,SNMP,SSH |
Supported security algorithms | 256-bit AES, FIPS 140-2, HTTPS, SNMP, SSH |
Supported browser | Apple Safari 7+, Google Chrome, Microsoft Internet Explorer 10+, Mozilla Firefox |
Software | |
Installed operating system | QNAP Turbo System |
version of the operating system | 5,0,0 |
Supported Linux operating systems | CentOS 7.0, Ubuntu 14.04 |
Supported server operating systems | Windows Server 2008 R2, Windows Server 2012, Windows Server 2012 R2, Windows Server 2016, Windows Server 2019 |
Support for other operating systems | IBM AIX 7.1, IBM AIX 7.2, Solaris 10 |
energy | |
Power supply placement | Eingebaut |
capacity of the power supply unit | 250 W |
Number of power supply units | 1 |
Power consumption (standard operation) | 50,858 W |
Power consumption (sleep mode) | 27,949 W |
AC input voltage | 100 - 240 V |
AC input frequency | 50 - 60 Hz |
fans voltage | 12 V |
output current | 3,5 A |
weight and dimensions | |
broad | 329,3 mm |
depth | 280,8 mm |
height | 188,2 mm |
Weight | 6,38 kg |
scope of delivery | |
Supplied cables | AC, LAN (RJ-45) |
number of screws | 56 |
operating conditions | |
operating temperatur | 0 - 40 °C |
Operating relative humidity | 5 - 95% |
Storage temperature range | -20 - 70 °C |
logistic data | |
Goods tariff number (HS) | 84714100 |
