Processor family | Intel® Celeron® |
Processor cores | 4 |
Processor model | N5105 |
Processor threads | 4 |
Processor manufacturer | Intel |
Processor frequency | 2 GHz |
On-board graphics card model | Intel® UHD Graphics |
CPU configuration (max) | 1 |
Processor boost frequency | 2.9 GHz |
Internal memory type | DDR4 |
Memory slots | 2 |
Memory Form Factor | SO-DIMM |
Flash Memory | 8000 MB |
Maximum RAM supported | 16 GB |
INTERNAL MEMORY | 8 GB |
Display type | LCD |
Cooling type | Active |
Fan Diameter | 12 cm |
Built-in Display | Yes |
Number of fans | 1 fan(s) |
Chassis type | Desktop |
Product colour | Black |
Power supply location | External |
Power consumption (HDD standby) | 27.7 W |
Power consumption (sleep) | 0.81 W |
Power supply unit (PSU) capacity | 250 W |
Power consumption (typical) | 48.5 W |
AC input voltage | 100 - 240 V |
Operating relative humidity (H-H) | 5 - 95% |
Operating temperature (T-T) | 0 - 40 °C |
Depth | 230 mm |
Height | 185.5 mm |
Width | 233 mm |
Weight | 4.4 kg |
Ethernet LAN | Yes |
Jumbo Frames support | Yes |
Ethernet LAN data rates | 2500 Mbit/s |
Wake-on-LAN ready | Yes |
Browser supported | Firefox, Chrome, Safari, Microsoft Edge |
Backup features | USB drive |
Type | NAS |
Noise level | 18.1 dB |
Backup function | Yes |
Device class | Home & Home Office |
Intel Trusted Execution Technology | No |
Intel 64 | Yes |
Enhanced Intel SpeedStep Technology | Yes |
Intel VT-x with Extended Page Tables (EPT) | Yes |
Idle States | Yes |
Intel Virtualization Technology for Directed I/O (VT-d) | Yes |
Intel Virtualization Technology (VT-x) | Yes |
Operating System Version | 4.1 |
Operating system installed | ADM |
Server operating systems supported | Windows Server 2019 |
Windows operating systems supported | Yes |
Linux operating systems supported | Yes |
Mac operating systems supported | MacOS |
Storage drives installed | Yes |
Number of storage drives supported | 6 |
RAID levels | 10 |
Supported file systems | ext4 |
Storage drive sizes supported | 3.5" |
Number of M.2 (M & B) slots | 4 |
Installed storage drive type | HDD |
Storage drive interface | M.2, Serial ATA, Serial ATA II, Serial ATA III |
Raid Support | Yes |
Supported storage drive types | HDD & SSD |
USB Port | Yes |
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 2 |
HDMI ports quantity | 1 |
HDMI version | 2.0b |
Ethernet LAN (RJ-45) ports | 2 |
Harmonized System (HS) code | 84714100 |
