storage medium | |
storage drive interface | M.2, Serial ATA III |
Storage drive size | 2.5/3.5" |
Eigenschaft | Unterstützte Linux-Betriebssysteme |
RAID Level | 0, 1, 5, 6, 10 |
Supported file systems | BTRFS, FAT32, HFS+, NTFS, exFAT, ext3, ext4 |
Total installed storage capacity | 0 TB |
Number of supported storage drives | 16 |
Supported storage drives | HDD & SSD |
processor | N5105 |
processor manufacturer | Intel |
processor family | Intel® Celeron® |
processor clock speed | 2 GHz |
Processor Boost Frequency | 2,9 GHz |
number of CPU cores | 4 |
processor threads | 4 |
processor cache | 4 MB |
CPU configuration (max) | 1 |
Storage | |
storage capacity | 4 GB |
Internal storage type | DDR4 |
memory clock speed | 2933 MHz |
Maximum supported RAM | 16 GB |
memory card slots | 2 |
Memory form factor | SO-DIMM |
Flash memory | 8192 MB |
network | |
Ethernet LAN data transfer rates | 10,100,1000,2500 Mbit/s |
Supported network protocols | CIFS / SMB, SMB 2.0 / 3.0, AFP, NFS, FTP (Unicode Supported), TFTP, WebDAV, Rsync, SSH, SFTP, iSCSI/IP-SAN, HTTP, HTTPS, Proxy, SNMP, Syslog |
connections and interfaces | |
USB 3.2 Gen 2 (3.1 Gen 2) Number of Type A ports | 3 |
Number of HDMI ports | 1 |
HDMI-Version | 2.0b |
Number of Ethernet LAN ports (RJ-45) | 2 |
Design | |
cooling | Aktiv |
Product color | Schwarz |
number of fans | 1 Lüfter |
fan diameter | 12 cm |
Services | |
Type | NAS |
device class | Home & Home Office |
backup functions | Cloud |
number of users | 4096 Benutzer |
noise level | 19,7 dB |
Supported security algorithms | 256-bit AES |
Supported browser | FireFox, Chrome, Safari, Microsoft Edge |
Software | |
Installed operating system | ADM |
version of the operating system | 4,1 |
Supports Windows operating systems | Windows 10, Windows 11, Windows 7, Windows 8, Windows Vista, Windows XP |
Supported server operating systems | Windows Server 2003, Windows Server 2008, Windows Server 2012, Windows Server 2016, Windows Server 2019, Windows Server 2022 |
energy | |
Power consumption (standard operation) | 38,3 W |
Power consumption (sleep mode) | 0,81 W |
AC input voltage | 100 - 240 V |
weight and dimensions | |
broad | 174 mm |
depth | 230 mm |
height | 170 mm |
Weight | 2,26 kg |
operating conditions | |
operating temperatur | 0 - 40 °C |
Operating relative humidity | 5 - 95% |
Other functions | |
certification | FCC, CE, VCCI, BSMI, C-TICK, KCC, BIS, CCC, UKCA |
