CPU configuration (max) | 1 |
Processor cores | 4 |
On-board graphics card model | Intel® UHD Graphics |
Processor manufacturer | Intel |
Processor family | Intel® Celeron® |
Processor threads | 4 |
Processor model | N5105 |
Processor frequency | 2 GHz |
Number of processors supported | 1 |
Processor boost frequency | 2.9 GHz |
Maximum RAM supported | 8 GB |
INTERNAL MEMORY | 8 GB |
Internal memory type | DDR4 |
Flash Memory | 4000 MB |
Chassis type | Desktop |
LED indicators | Yes |
Product colour | Black |
Cooling type | Active |
Number of fans | 1 fan(s) |
Cable lock slot type | Kensington |
Cable lock slot | Yes |
Power supply unit (PSU) capacity | 65 W |
Number of power supply units | 1 |
AC input voltage | 100 - 240 V |
Power consumption (sleep) | 18 W |
Power consumption (typical) | 28 W |
Power supply location | External |
Operating temperature (T-T) | 0 - 40 °C |
Storage temperature (T-T) | -20 - 70 °C |
Operating relative humidity (H-H) | 5 - 95% |
PACKAGE WEIGHT | 1.7 kg |
Height | 30 mm |
Width | 230 mm |
Weight | 800 g |
Depth | 165 mm |
Ethernet LAN | Yes |
Wake-on-LAN ready | Yes |
Ethernet LAN data rates | 100 Mbit/s |
Jumbo Frames support | Yes |
DHCP Server | Yes |
iSCSI support | Yes |
Dynamic DNS (DDNS) | Yes |
Multilingual support | Yes |
Security algorithms | HTTPS |
Browser supported | Mozilla Firefox, Microsoft Edge, Google Chrome, Apple Safari |
Access Control List (ACL) | Yes |
Type | NAS |
Device class | Home & Home Office |
Backup function | Yes |
Reset button | Yes |
Hot Spare | Yes |
Snapshot | Yes |
Backup features | Cloud |
S.M.A.R.T. support | Yes |
On/off switch | Yes |
Noise level | 25 dB |
Buzzer | Yes |
Built-in FTP server | Yes |
CABLES INCLUDED | LAN (RJ-45) |
External power adapter | Yes |
Power cables quantity | 1 |
Intel Virtualization Technology for Directed I/O (VT-d) | Yes |
Idle States | Yes |
Intel Virtualization Technology (VT-x) | Yes |
Enhanced Intel SpeedStep Technology | Yes |
Intel Trusted Execution Technology | No |
Intel 64 | Yes |
Intel VT-x with Extended Page Tables (EPT) | Yes |
Operating System Version | 5.0.0 |
Windows operating systems supported | Yes |
Operating system installed | QNAP Turbo System |
Linux operating systems supported | Yes |
Mac operating systems supported | Yes |
Supported file systems | ext3 |
Supported storage drive interfaces | M.2 |
Online RAID expansion | Yes |
RAID levels | 0 |
Disk roaming | Yes |
Installed storage drive type | No |
Number of storage drives supported | 4 |
Storage drives installed | No |
Online RAID migration | Yes |
Number of M.2 (M & B) slots | 4 |
Supported storage drive types | SSD |
Raid Support | Yes |
Ethernet LAN (RJ-45) ports | 2 |
HDMI ports quantity | 2 |
USB 2.0 ports quantity | 3 |
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 2 |
HDMI version | 2.0 |
USB Port | Yes |
Harmonized System (HS) code | 84714100 |
