storage medium | |
Supported storage drive interfaces | Serial ATA III, Serial ATA II |
supported storage drive sizes | 2.5,3.5" |
Eigenschaft | Laufwerksschachtschlüssel enthalten |
RAID Level | 0, 1, 5, 6, 10, JBOD |
Supported file systems | FAT32, HFS+, NTFS, exFAT, ext3, ext4 |
Total installed storage capacity | 0 TB |
Number of supported storage drives | 4 |
Supported storage drives | HDD & SSD |
processor | Cortex-A55 |
processor family | ARM |
processor clock speed | 2 GHz |
number of CPU cores | 4 |
processor architecture | ARM Cortex-A55 |
Storage | |
storage capacity | 4 GB |
Maximum supported RAM | 4 GB |
Flash memory | 4000 MB |
network | |
Ethernet LAN data transfer rates | 100,1000,2500 Mbit/s |
connections and interfaces | |
Number of USB 2.0 ports | 2 |
USB 3.2 Gen 1 (3.1 Gen 1) Number of Type A ports | 1 |
Number of Ethernet LAN ports (RJ-45) | 2 |
Simultaneous Connections | 200 |
Design | |
case type | Tower |
cooling | Aktiv |
Product color | Weiß |
number of fans | 1 Lüfter |
fan diameter | 12 cm |
LED indicators | Leistung, Reset, USB |
Lock-Type Cable Barrier | Kensington |
Services | |
Type | NAS |
device class | Home & Home Office |
backup functions | Cloud, iSCSI LUN |
management logs | SNMP V2/V3 |
Supported security algorithms | 256-bit AES, FIPS 140-2, HTTPS, SSH |
Supported browser | Apple Safari, Google Chrome, Microsoft Edge, Mozilla Firefox |
Software | |
Installed operating system | QNAP QTS |
version of the operating system | 5,0,1 |
Supports Windows operating systems | Windows 10, Windows 11, Windows 7, Windows 8 |
Supported server operating systems | Windows Server 2008, Windows Server 2012, Windows Server 2012 R2, Windows Server 2016, Windows Server 2019 |
energy | |
Power supply placement | Extern |
capacity of the power supply unit | 90 W |
Power consumption (standard operation) | 22,54 W |
Power consumption (HDD standby) | 8,45 W |
AC input voltage | 100 - 240 V |
fans voltage | 12 V |
weight and dimensions | |
broad | 160 mm |
depth | 219 mm |
height | 169 mm |
Weight | 2,07 kg |
package weight | 3,5 kg |
scope of delivery | |
Supplied cables | AC, LAN (RJ-45) |
Anzahl Stromkabel | 1 |
number of screws | 28 |
operating conditions | |
operating temperatur | 0 - 40 °C |
Operating relative humidity | 5 - 95% |
Storage temperature range | -20 - 70 °C |
