Processor model | CN9131 |
Processor cores | 4 |
Processor manufacturer | Marvell |
Processor family | Marvell |
Processor frequency | 2.2 GHz |
Internal memory type | DDR4 |
Memory Form Factor | SO-DIMM |
Maximum RAM supported | 32 GB |
INTERNAL MEMORY | 4 GB |
Memory slots | 1 |
Flash Memory | 4000 MB |
LED indicators | Yes |
Fan Diameter | 4 cm |
Cooling type | Active |
Product colour | Grey |
Chassis type | Rack (1U) |
Cable lock slot type | Kensington |
Number of fans | 3 fan(s) |
Cable lock slot | Yes |
Power supply location | Built-in |
Fan voltage | 12 V |
AC input voltage | 100 - 240 V |
Power consumption (typical) | 30.878 W |
Power supply unit (PSU) capacity | 100 W |
Power consumption (HDD standby) | 17.367 W |
AC input frequency | 50 - 60 Hz |
Number of power supply units | 1 |
Operating temperature (T-T) | 0 - 40 °C |
Storage temperature (T-T) | -20 - 70 °C |
Operating relative humidity (H-H) | 5 - 95% |
Depth | 292.1 mm |
Width | 430 mm |
Weight | 4.17 kg |
Height | 43.3 mm |
Load balancing system | Yes |
iSCSI support | Yes |
DHCP client | Yes |
DHCP Server | Yes |
Ethernet LAN data rates | 100 |
Wake-on-LAN ready | Yes |
Ethernet LAN | Yes |
Link aggregation | Yes |
Dynamic DNS (DDNS) | Yes |
Jumbo Frames support | Yes |
Multilingual support | Yes |
Type | NAS |
Backup function | Yes |
Remotely operated | Yes |
Access Control List (ACL) | Yes |
Buzzer | Yes |
Snapshot | Yes |
Share folder | Y |
Reset button | Yes |
Hot Spare | Yes |
Disk scan | Yes |
Backup features | iSCSI LUN |
S.M.A.R.T. support | Yes |
Device class | Small & Medium Business |
Built-in FTP server | Yes |
On/off switch | Yes |
Browser supported | Apple Safari, Google Chrome, Microsoft Edge, Mozilla Firefox, Microsoft Edge |
Universal Plug and Play (UPnP) | Yes |
System log | Yes |
Number of screws | 28 |
Power cables quantity | 1 |
CABLES INCLUDED | AC |
Rack mount kit | Yes |
Server operating systems supported | Windows Server 2019 |
Linux operating systems supported | Yes |
Windows operating systems supported | Yes |
Mac operating systems supported | Yes |
Operating system installed | QNAP QTS |
Operating System Version | 5.0.0 |
Raid Support | Yes |
Storage drive sizes supported | 2.5 |
Installed storage drive type | No |
RAID levels | 1 |
Number of storage drives supported | 4 |
Supported file systems | HFS+ |
Supported storage drive types | HDD & SSD |
Hot-swap drive bays | Yes |
Online RAID expansion | Yes |
Bad block scan | Yes |
Total installed storage capacity | 0 TB |
Online RAID migration | Yes |
Auto-rebuild | Yes |
Supported storage drive interfaces | M.2, Serial ATA II, Serial ATA III |
RAID rebuild | Yes |
Disk roaming | Yes |
Storage drives installed | No |
USB 2.0 ports quantity | 2 |
USB Port | Yes |
Concurrent connections | 1500 |
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 2 |
Fiber optic connector | SFP+ |
Fiber ports quantity | 2 |
Ethernet LAN (RJ-45) ports | 2 |
Harmonized System (HS) code | 84714100 |
Warnings | Do not dispose of the device in the regular rubbish bin. The product requires special disposal. |
