Processor cores | 2 |
Processor threads | 2 |
Processor boost frequency | 2.9 GHz |
Processor manufacturer | Intel |
On-board graphics card model | Intel® UHD Graphics |
Processor family | Intel® Celeron® |
Processor frequency | 2 GHz |
Processor model | N4505 |
CPU configuration (max) | 1 |
Number of processors supported | 1 |
Internal memory type | DDR4 |
INTERNAL MEMORY | 4 GB |
Memory slots | 2 |
Memory Form Factor | SO-DIMM |
Flash Memory | 4000 MB |
Maximum RAM supported | 16 GB |
Cooling type | Active |
LED indicators | Status |
Cable lock slot | Yes |
Fan Diameter | 12 cm |
Product colour | White |
Number of fans | 1 fan(s) |
Cable lock slot type | Kensington |
Chassis type | Tower |
Power consumption (sleep) | 11.3 W |
Power supply unit (PSU) capacity | 90 W |
Fan voltage | 12 V |
Number of power supply units | 1 |
AC input voltage | 100 - 240 V |
Power supply location | External |
Power consumption (typical) | 25.98 W |
Operating relative humidity (H-H) | 5 - 95% |
Storage relative humidity (H-H) | 5 - 95% |
Operating temperature (T-T) | 0 - 40 °C |
Storage temperature (T-T) | -20 - 70 °C |
PACKAGE WEIGHT | 3.6 kg |
Weight | 2.26 kg |
Height | 168 mm |
Width | 170 mm |
Depth | 226 mm |
Ethernet LAN data rates | 2500 Mbit/s |
Wake-on-LAN ready | Yes |
iSCSI support | Yes |
Ethernet LAN | Yes |
Jumbo Frames support | Yes |
DHCP Server | Yes |
Dynamic DNS (DDNS) | Yes |
Backup features | iSCSI LUN |
Multilingual support | Yes |
Password authentication | Yes |
Access Control List (ACL) | Yes |
Security algorithms | HTTPS |
USB copy function | Yes |
Backup function | Yes |
On/off switch | Yes |
Share folder | Y |
Disk scan | Yes |
Snapshot | Yes |
Reset button | Yes |
Hot Spare | Yes |
Built-in FTP server | Yes |
Browser supported | Apple Safari, Google Chrome, Microsoft Edge, Mozilla Firefox |
S.M.A.R.T. support | Yes |
Type | NAS |
Device class | Home & Home Office |
Buzzer | Yes |
System log | Yes |
CABLES INCLUDED | LAN (RJ-45) |
Power cables quantity | 1 |
Intel Virtualization Technology for Directed I/O (VT-d) | Yes |
Intel Virtualization Technology (VT-x) | Yes |
Intel Trusted Execution Technology | No |
Enhanced Intel SpeedStep Technology | Yes |
Idle States | Yes |
Intel VT-x with Extended Page Tables (EPT) | Yes |
Intel 64 | Yes |
Operating system installed | QNAP QTS |
Mac operating systems supported | Mac OS X 10.14 Mojave |
Windows operating systems supported | Windows 7 |
Server operating systems supported | Windows Server 2008 R2 |
Operating System Version | 5.0.1 |
Linux operating systems supported | Yes |
RAID levels | 1 |
Number of storage drives supported | 4 |
Raid Support | Yes |
Storage Drive Capacity | 0 GB |
Supported storage drive types | HDD & SSD |
Supported file systems | ext4 |
RAID rebuild | Yes |
Online RAID expansion | Yes |
Bad block scan | Yes |
Disk roaming | Yes |
Storage drive sizes supported | 2.5 |
Online RAID migration | Yes |
Total installed storage capacity | 0 TB |
Storage drives installed | No |
Installed storage drive type | No |
Number of M.2 (M & B) slots | 2 |
Supported storage drive interfaces | Serial ATA III |
Hot-swap drive bays | Yes |
Ethernet LAN (RJ-45) ports | 1 |
USB Port | Yes |
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 2 |
HDMI version | 2.0 |
HDMI ports quantity | 1 |
USB 2.0 ports quantity | 2 |
Warnings | Do not dismantle the appliance yourself. |
