CPU configuration (max) | 1 |
Processor threads | 4 |
Processor model | N5095 |
Processor boost frequency | 2.9 GHz |
On-board graphics card model | Intel® UHD Graphics |
Processor manufacturer | Intel |
Processor family | Intel® Celeron® |
Processor cores | 4 |
INTERNAL MEMORY | 8 GB |
Flash Memory | 4000 MB |
Maximum RAM supported | 8 GB |
LED indicators | Status |
Fan Diameter | 4 cm |
Product colour | Black |
Number of fans | 2 fan(s) |
Chassis type | Rack (1U) |
Cooling type | Active |
Power supply location | Built-in |
Power supply unit (PSU) capacity | 250 W |
AC input voltage | 100 - 240 V |
Power consumption (typical) | 51.404 W |
Redundant power supply (RPS) support | Yes |
Power consumption (HDD standby) | 37.469 W |
Number of power supply units | 2 |
Fan voltage | 12 V |
Operating temperature (T-T) | 0 - 40 °C |
Storage relative humidity (H-H) | 5 - 95% |
Operating relative humidity (H-H) | 5 - 95% |
Storage temperature (T-T) | -20 - 70 °C |
Depth | 479 mm |
Weight | 8.12 kg |
Height | 43.3 mm |
PACKAGE WEIGHT | 10.1 kg |
Width | 430 mm |
Ethernet LAN data rates | 10 |
Wake-on-LAN ready | Yes |
Ethernet LAN | Yes |
Jumbo Frames support | Yes |
DHCP Server | Yes |
DHCP client | Yes |
iSCSI support | Yes |
Dynamic DNS (DDNS) | Yes |
Snapshot | Yes |
Security algorithms | 256-bit AES |
S.M.A.R.T. support | Yes |
Disk scan | Yes |
Backup features | Cloud |
Backup function | Yes |
System log | Yes |
Multilingual support | Yes |
Reset button | Yes |
Hot Spare | Yes |
Type | NAS |
On/off switch | Yes |
Buzzer | Yes |
Share folder | CIFS/SMB |
Built-in FTP server | Yes |
Device class | Small & Medium Business |
Access Control List (ACL) | Yes |
Browser supported | Apple Safari, Google Chrome, Microsoft Edge, Mozilla Firefox |
CABLES INCLUDED | LAN (RJ-45) |
Power cables quantity | 2 |
Number of screws | 84 |
Intel 64 | Yes |
Intel Virtualization Technology for Directed I/O (VT-d) | Yes |
Intel Virtualization Technology (VT-x) | Yes |
Idle States | Yes |
Enhanced Intel SpeedStep Technology | Yes |
Intel VT-x with Extended Page Tables (EPT) | Yes |
Intel Trusted Execution Technology | No |
Other operating systems supported | Solaris 10 |
Server operating systems supported | Windows Server 2012 R2 |
Operating system installed | QNAP Turbo System |
Windows operating systems supported | Windows 8 |
Operating System Version | 5.0.1 |
Mac operating systems supported | Yes |
Linux operating systems supported | Yes |
RAID levels | 6 |
Online RAID migration | Yes |
Supported file systems | FAT32 |
Supported storage drive interfaces | Serial ATA II, Serial ATA III |
Supported storage drive types | HDD & SSD |
Disk roaming | Yes |
Online RAID expansion | Yes |
RAID rebuild | Yes |
Storage drive sizes supported | 2.5 |
Storage drives installed | No |
Installed storage drive type | No |
Hot-swap drive bays | Yes |
Number of storage drives supported | 4 |
Raid Support | Yes |
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 2 |
Ethernet LAN (RJ-45) ports | 2 |
USB 2.0 ports quantity | 2 |
HDMI ports quantity | 1 |
Concurrent connections | 1500 |
HDMI version | 1.4b |
USB Port | Yes |
PCI Express x2 (Gen 3.x) slots | 1 |
Harmonized System (HS) code | 84714100 |
