Processor cores | 4 |
Processor family | Ryzen Embedded |
Number of processors supported | 1 |
Processor frequency | 2.2 GHz |
Processor threads | 8 |
Processor generation | AMD Ryzen Embedded V1000 Series |
Processor model | V1500B |
Processor manufacturer | AMD |
Memory slots | 2 |
Flash Memory | 5000 MB |
Maximum RAM supported | 64 GB |
Memory Form Factor | SO-DIMM |
ETC | Yes |
INTERNAL MEMORY | 8 GB |
Internal memory type | DDR4 |
Product colour | Black |
LED indicators | HDD |
Cooling type | Active |
Cable lock slot | Yes |
Number of fans | 3 fan(s) |
Housing material | Metal |
Fan Diameter | 6 cm |
Fan diameter 2 | 9.2 cm |
Chassis type | Tower |
Cable lock slot type | Kensington |
AC input voltage | 100 - 240 V |
AC input frequency | 50 - 60 Hz |
Number of power supply units | 1 |
Power consumption (sleep) | 21.891 W |
Power supply location | Built-in |
Power supply unit (PSU) capacity | 250 W |
Power consumption (typical) | 45.898 W |
Operating relative humidity (H-H) | 5 - 95% |
Operating temperature (T-T) | 0 - 40 °C |
Storage temperature (T-T) | -20 - 70 °C |
Weight | 5.78 kg |
Height | 188.2 mm |
Depth | 280.8 mm |
Width | 264.3 mm |
Wake-on-LAN ready | Yes |
Ethernet LAN data rates | 5000 |
iSCSI support | Yes |
Jumbo Frames support | Yes |
Dynamic DNS (DDNS) | Yes |
DHCP Server | Yes |
Ethernet LAN | Yes |
Noise level | 20.3 dB |
Device class | Small & Medium Business |
Access Control List (ACL) | Yes |
Reset button | Yes |
Type | NAS |
Security algorithms | SSH |
Built-in FTP server | Yes |
Backup features | Cloud |
Browser supported | Apple Safari, Google Chrome, Microsoft Edge, Mozilla Firefox |
Snapshot | Yes |
S.M.A.R.T. support | Yes |
Password authentication | Yes |
Buzzer | Yes |
Backup function | Yes |
Hot Spare | Yes |
Remotely operated | Yes |
On/off switch | Yes |
Other operating systems supported | Solaris 10 |
Operating system installed | QNAP Turbo System |
Server operating systems supported | Windows Server 2019 |
Operating System Version | 5.0.0 |
Linux operating systems supported | Ubuntu 14.04 |
Windows operating systems supported | Windows 10 |
Mac operating systems supported | Mac OS X 10.15 Catalina |
Supported storage drive types | HDD & SSD |
RAID levels | 6 |
Raid Support | Yes |
RAID rebuild | Yes |
Storage drives installed | No |
Supported storage drive interfaces | M.2, Serial ATA II, Serial ATA III |
Storage drive interface | M.2, Serial ATA II, Serial ATA III |
Storage Drive Capacity | 0 GB |
Installed storage drive type | No |
Supported file systems | FAT32 |
Number of M.2 (M & B) slots | 2 |
Storage drive sizes supported | 3.5" |
Total installed storage capacity | 0 TB |
Hot-swap drive bays | Yes |
System drive capacity | 5 GB |
Number of storage drives supported | 8 |
Number of system drives installed | 1 |
Ethernet LAN (RJ-45) ports | 2 |
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity | 1 |
Concurrent connections | 2000 |
USB Port | Yes |
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 3 |
Harmonized System (HS) code | 84714100 |
