Thermal Design Power (TDP) | 50 W |
Number of Processors Installed | 1 |
ECC supported by processor | Yes |
Processor threads | 8 |
Processor frequency | 2.8 GHz |
Processor model | C5125 |
Processor cores | 8 |
Processor cache | 9 MB |
Processor family | Intel Atom® |
Processor manufacturer | Intel |
Maximum RAM supported | 64 GB |
Memory slots | 2 |
Internal memory type | DDR4 |
Memory Form Factor | SO-DIMM |
INTERNAL MEMORY | 8 GB |
Flash Memory | 5000 MB |
Fan Diameter | 6 cm |
Cooling type | Active |
LED indicators | Yes |
Number of fans | 3 fan(s) |
Chassis type | Rack (2U) |
Product colour | Black |
Number of power supply units | 1 |
Fan voltage | 12 V |
Power supply unit (PSU) capacity | 250 W |
Power supply location | Built-in |
Power consumption (typical) | 79.113 W |
AC input voltage | 100 - 240 V |
Power consumption (sleep) | 49.799 W |
Storage temperature (T-T) | -20 - 70 °C |
Operating relative humidity (H-H) | 5 - 95% |
Operating temperature (T-T) | 0 - 40 °C |
Weight | 7.61 kg |
Width | 432 mm |
Depth | 297.4 mm |
Height | 88.6 mm |
Ethernet LAN data rates | 1000 |
Ethernet LAN | Yes |
iSCSI support | Yes |
Wake-on-LAN ready | Yes |
Supported network protocols | IPv4, IPv6 |
Jumbo Frames support | Yes |
DHCP Server | Yes |
Dynamic DNS (DDNS) | Yes |
Browser supported | Apple Safari (latest version) Google Chrome (latest version) Microsoft Edge (latest version) Mozilla Firefox (latest version) |
Security algorithms | SSH |
Access Control List (ACL) | Yes |
Backup features | USB drive |
System log | Yes |
USB copy function | Yes |
Buzzer | Yes |
Snapshot | Yes |
Type | SAN |
Device class | Home & Home Office |
Management protocols | SNMP V2, V3 |
Backup function | Yes |
S.M.A.R.T. support | Yes |
Share folder | CIFS/SMB |
Built-in FTP server | Yes |
Reset button | Yes |
Hot Spare | Yes |
On/off switch | Yes |
CABLES INCLUDED | LAN (RJ-45) |
Quick installation guide | Yes |
Power cables quantity | 1 |
Number of screws | 56 |
Mac operating systems supported | Yes |
Linux operating systems supported | Ubuntu 14.04 |
Operating System Version | h5.0.1 |
Windows operating systems supported | Windows 11 |
Other operating systems supported | IBM AIX 7.1 |
Server operating systems supported | Windows Server 2012 |
Operating system installed | QuTS hero |
Storage drive sizes supported | 3.5 |
Online RAID migration | Yes |
Installed storage drive type | No |
Number of M.2 (M & B) slots | 2 |
Disk roaming | Yes |
RAID levels | JBOD |
Supported file systems | FAT32 |
Raid Support | Yes |
Supported storage drive types | HDD & SSD |
Number of storage drives supported | 8 |
RAID rebuild | Yes |
Storage drives installed | No |
Online RAID expansion | Yes |
Supported storage drive interfaces | Serial ATA III, Serial ATA II |
Hot-swap drive bays | Yes |
PCI Express x4 (Gen 3.x) slots | 2 |
Ethernet LAN (RJ-45) ports | 2 |
USB Port | Yes |
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 4 |
Fiber optic connector | MTP |
Fibre Channel | Yes |
