Number of processors supported | 1 |
Processor cores | 4 |
Processor generation | AMD Ryzen Embedded V1000 Series |
Processor manufacturer | AMD |
Processor threads | 8 |
Processor frequency | 2.2 GHz |
Processor model | V1500B |
Processor family | Ryzen Embedded |
INTERNAL MEMORY | 8 GB |
ETC | Yes |
Flash Memory | 5000 MB |
Internal memory type | DDR4 |
Memory slots | 2 |
Memory Form Factor | SO-DIMM |
Maximum RAM supported | 64 GB |
LED indicators | HDD |
Product colour | Black |
Chassis type | Tower |
Cable lock slot type | Kensington |
Fan diameter 2 | 6 cm |
Cable lock slot | Yes |
Number of fans | 3 fan(s) |
Fan Diameter | 12 cm |
Cooling type | Active |
Power consumption (HDD standby) | 25.668 W |
AC input voltage | 100 - 240 V |
AC input frequency | 50 - 60 Hz |
Power consumption (sleep) | 25.668 W |
Power supply unit (PSU) capacity | 250 W |
Power consumption (typical) | 54.067 W |
Power supply location | Built-in |
Storage temperature (T-T) | -20 - 70 °C |
Operating temperature (T-T) | 0 - 40 °C |
Operating relative humidity (H-H) | 5 - 95% |
Height | 188.2 mm |
Width | 329.3 mm |
Depth | 280.8 mm |
Weight | 6.76 kg |
iSCSI support | Yes |
Ethernet LAN data rates | 100 Mbit/s |
Jumbo Frames support | Yes |
Ethernet LAN | Yes |
Wake-on-LAN ready | Yes |
DHCP Server | Yes |
Buzzer | Yes |
Device class | Small & Medium Business |
Backup features | Cloud |
On/off switch | Yes |
Type | NAS |
Multilingual support | Yes |
Built-in FTP server | Yes |
Backup function | Yes |
Access Control List (ACL) | Yes |
Reset button | Yes |
USB copy function | Yes |
S.M.A.R.T. support | Yes |
Remotely operated | Yes |
Noise level | 23 dB |
Power cables quantity | 1 |
CABLES INCLUDED | LAN (RJ-45) |
Windows operating systems supported | Windows 8 |
Linux operating systems supported | Yes |
Operating System Version | 5.0.0 |
Mac operating systems supported | Mac OS X 10.10 Yosemite |
Server operating systems supported | Windows Server 2012 |
Operating system installed | QNAP Turbo System |
RAID levels | 5 |
Number of storage drives supported | 8 |
Supported file systems | exFAT |
Online RAID expansion | Yes |
Storage drive sizes supported | M.2 |
Storage Drive Capacity | 0 GB |
Storage drive interface | Serial ATA III |
Storage drives installed | No |
Number of system drives installed | 1 |
RAID rebuild | Yes |
System drive capacity | 5 GB |
Number of M.2 (M & B) slots | 2 |
Total installed storage capacity | 0 TB |
Supported storage drive types | HDD & SSD |
Supported storage drive interfaces | M.2, Serial ATA II, Serial ATA III |
Online RAID migration | Yes |
Hot-swap drive bays | Yes |
Raid Support | Yes |
Installed storage drive type | No |
Ethernet LAN (RJ-45) ports | 2 |
Concurrent connections | 2000 |
PCI Express x4 (Gen 3.x) slots | 2 |
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 3 |
USB Port | Yes |
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity | 1 |
Harmonized System (HS) code | 84714100 |
