Sustainability compliance | Yes |
Sustainability certificates | RoHS |
Processor manufacturer | AMD |
Processor boost frequency | 3.1 GHz |
Processor frequency | 2.6 GHz |
Processor cores | 2 |
Processor family | AMD Embedded R-Series SoC |
Processor model | R1600 |
Maximum RAM supported | 32 GB |
ETC | Yes |
Memory Form Factor | SO-DIMM |
INTERNAL MEMORY | 8 GB |
Memory slots | 2 |
Internal memory type | DDR4 |
Product colour | Black |
Drive bay locking | Yes |
Chassis type | Tower |
Cooling type | Active |
Built-in Display | No |
LED indicators | Yes |
Fan Diameter | 9.2 cm |
Number of fans | 2 fan(s) |
Cable lock slot type | Kensington |
Cable lock slot | Yes |
Power supply unit (PSU) capacity | 120 W |
Number of power supply units | 1 |
Power supply location | External |
Power consumption (HDD standby) | 16.71 W |
Power consumption (typical) | 52.06 W |
AC input frequency | 50 - 60 Hz |
AC input voltage | 100 - 240 V |
Redundant power supply (RPS) support | No |
Operating temperature (T-T) | 0 - 40 °C |
Operating relative humidity (H-H) | 5 - 95% |
Storage temperature (T-T) | -20 - 60 °C |
Weight | 2.7 kg |
Width | 230 mm |
Height | 166 mm |
Depth | 223 mm |
Wake-on-LAN ready | Yes |
iSCSI support | Yes |
Ethernet LAN data rate supported (max) | 10000 Mbit/s |
Link aggregation | Yes |
Ethernet LAN data rates | 10 |
Copper ethernet cabling technology | 1000BASE-T |
Ethernet LAN | Yes |
Supported network protocols | SMB1 (CIFS), SMB2, SMB3, NFSv3, NFSv4, NFSv4.1, NFS Kerberized sessions, iSCSI, HTTP, HTTPs, FTP, SNMP, LDAP, CalDAV |
Web-based management | Yes |
Hot Spare | Yes |
Device class | Home & Home Office |
Access Control List (ACL) | Yes |
Built-in UPnP AV media server | Yes |
Card reader integrated | No |
Management protocols | SNMP |
Backup features | iSCSI LUN |
Multilingual support | Yes |
Number of users | 2048 user(s) |
On/off switch | Yes |
Snapshot | Yes |
Video input channels | 2 channels |
Noise level | 22.9 dB |
Reset button | Yes |
Browser supported | Google Chrome, Firefox, Microsoft Edge, Safari |
Security algorithms | HTTPS |
Backup function | Yes |
Type | NAS |
CABLES INCLUDED | AC |
Power cables quantity | 1 |
Remote control included | No |
External power adapter | Yes |
Operating System Version | 7.1 |
Windows operating systems supported | Yes |
Operating system installed | DiskStation Manager |
Supported storage drive types | HDD & SSD |
Supported file systems | BTRFS |
Number of M.2 (M & B) slots | 2 |
Online RAID migration | Yes |
Online RAID expansion | Yes |
Number of storage drives supported | 5 |
Supported storage drive interfaces | Serial ATA II, Serial ATA III |
RAID levels | 10 |
Installed storage drive type | No |
Raid Support | Yes |
Storage drives installed | No |
Hot-swap drive bays | Yes |
Storage drive sizes supported | 2.5 |
eSATA ports quantity | 2 |
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 2 |
Ethernet LAN (RJ-45) ports | 4 |
USB Port | Yes |
Harmonized System (HS) code | 84714100 |
