storage medium | |
storage capacity | 8 GB |
storage drive interface | Serial Attached SCSI (SAS) |
supported storage drive sizes | 2.5,3.5" |
Eigenschaft | Unterstützung für redundantes Netzteil |
RAID Level | 0, 1, 5, 10, JBOD |
Supported file systems | BTRFS, ext4 |
Total installed storage capacity | 0 TB |
Number of supported storage drives | 12 |
Supported storage drives | HDD & SSD |
processor | D-1541 |
processor manufacturer | Intel |
processor family | Intel® Xeon® D |
processor clock speed | 2,1 GHz |
Processor Boost Frequency | 2,7 GHz |
number of CPU cores | 8 |
processor cache | 12 MB |
CPU configuration (max) | 1 |
Storage | |
Internal storage type | DDR4 |
Maximum supported RAM | 64 GB |
network | |
Ethernet LAN data transfer rates | 10,100,1000,10000 Mbit/s |
Supported network protocols | SMB1 (CIFS), SMB2, SMB3, NFSv3, NFSv4, NFSv4.1, NFS Kerberized sessions, iSCSI, Fibre Channel, HTTP, HTTPs, FTP, SNMP, LDAP, CalDAV |
connections and interfaces | |
Number of Ethernet LAN ports (RJ-45) | 3 |
Design | |
case type | Rack (2U) |
cooling | Aktiv |
number of fans | 2 Lüfter |
fan diameter | 6 cm |
Services | |
Type | NAS |
energy | |
capacity of the power supply unit | 500 W |
Number of power supply units | 2 |
AC input voltage | 100 - 240 V |
AC input frequency | 50/60 Hz |
weight and dimensions | |
broad | 482 mm |
depth | 724 mm |
height | 88 mm |
Weight | 19,7 kg |
Processor specifics | |
Intel® Secure Key Technologieversion | 1,00 |
Intel® TSX-NI-Version | 1,00 |
operating conditions | |
operating temperatur | 0 - 35 °C |
Operating relative humidity | 5 - 95% |
Storage temperature range | -20 - 60 °C |
