| Processor frequency | 2.2 GHz |
| Processor model | V1500B |
| Processor manufacturer | AMD |
| L2 CACHE | 2 MB |
| Number of processors supported | 1 |
| Processor threads | 8 |
| Processor family | Ryzen Embedded |
| On-board graphics card model | Not available |
| Processor generation | AMD Ryzen Embedded V1000 Series |
| Processor cores | 4 |
| L3 CACHE | 4 MB |
| INTERNAL MEMORY | 2 GB |
| Internal memory type | DDR4 |
| Memory slots | 2 |
| ETC | Yes |
| Memory Form Factor | SO-DIMM |
| Maximum RAM supported | 32 GB |
| Chassis type | Rack (1U) |
| LED indicators | Alarm |
| Cooling type | Active |
| Product colour | Grey |
| Drive bay locking | Yes |
| Fan Diameter | 4 cm |
| Number of fans | 2 fan(s) |
| Power consumption (typical) | 47.69 W |
| AC input frequency | 50/60 Hz |
| AC input voltage | 100 - 240 V |
| Power supply location | Built-in |
| Power supply unit (PSU) capacity | 150 W |
| Power consumption (HDD standby) | 16.7 W |
| Redundant power supply (RPS) support | Yes |
| Storage temperature (T-T) | -20 - 60 °C |
| Operating altitude | 0 - 5000 m |
| Operating temperature (T-T) | 0 - 35 °C |
| Operating relative humidity (H-H) | 8 - 80% |
| Storage relative humidity (H-H) | 5 - 95% |
| Height | 44 mm |
| Depth | 518.6 mm |
| Weight | 8 kg |
| Width | 480 mm |
| Ethernet LAN data rates | 1000 |
| Supported network protocols | SMB1 (CIFS), SMB2, SMB3, NFSv3, NFSv4, NFSv4.1, NFS Kerberized sessions, iSCSI, HTTP, HTTPs, FTP, SNMP, LDAP, CalDAV |
| iSCSI support | Yes |
| Link aggregation | Yes |
| Ethernet LAN | Yes |
| Wake-on-LAN ready | Yes |
| WLAN adapter supported | Yes |
| Access Control List (ACL) | Yes |
| Third-party support | Yes |
| Built-in iTunes server | Yes |
| Snapshot | Yes |
| Reset button | Yes |
| Hot Spare | Yes |
| System log | Yes |
| On/off switch | Yes |
| Noise level | 38.8 dB |
| Share folder | SMB/AFP/NFS/FTP/WebDAV |
| Browser supported | Google Chrome, Firefox, Microsoft Edge, Safari |
| Multilingual support | Yes |
| Built-in FTP server | Yes |
| Backup features | iSCSI LUN |
| Backup function | Yes |
| Security algorithms | SSL/TLS |
| Device class | Small & Medium Business |
| Type | NAS |
| Number of users | 2048 user(s) |
| CABLES INCLUDED | AC |
| Power cables quantity | 2 |
| Operating system installed | DiskStation Manager |
| Mac operating systems supported | Yes |
| Windows operating systems supported | Yes |
| Linux operating systems supported | Yes |
| Raid Support | Yes |
| Storage drives installed | No |
| Online RAID expansion | Yes |
| RAID levels | 10 |
| Supported file systems | ext4 |
| Installed storage drive type | No |
| Storage drive sizes supported | 3.5" |
| Total installed storage capacity | 0 TB |
| Supported storage drive interfaces | Serial ATA II, Serial ATA III |
| Online RAID migration | Yes |
| Supported storage drive types | HDD & SSD |
| Hot-swap drive bays | Yes |
| Number of storage drives supported | 4 |
| eSATA ports quantity | 1 |
| Concurrent connections | 500 |
| USB Port | Yes |
| Ethernet LAN (RJ-45) ports | 4 |
| PCI Express x8 (Gen 3.x) slots | 1 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 2 |
| Certification | FCC
CE
BSMI
VCCI
RCM
UKCA
EAC
CCC
KC
UL |
| Compliance certificates | RoHS |
