Pin assignment & polarity | 1/2 (-), 3/6 (+),4/5 (+), 7/8 (-) |
Power protection features | Over power |
Wall mountable | Yes |
LED indicators | Power |
Product colour | Black |
AC adapter input voltage | 100 - 240 V |
Input current | 1 A |
Power over Ethernet (PoE) voltage | 52 V |
Total Power over Ethernet (PoE) budget | 90 W |
DC output voltage | 56 V |
AC adapter frequency | 50/60 Hz |
Operating relative humidity (H-H) | 0 - 80% |
Storage relative humidity (H-H) | 0 - 80% |
Operating temperature (T-T) | 0 - 45 °C |
Storage temperature (T-T) | -20 - 70 °C |
Height | 46 mm |
Depth | 80 mm |
Width | 178.5 mm |
Ethernet LAN data rates | 100 Mbit/s |
Cabling technology | 10/100 |
Networking standards | IEEE 802.3at |
Power Over Ethernet (PoE) | Yes |
Ethernet interface type | Gigabit Ethernet |
Package Type | Box |
Number of products included | 1 pc(s) |
Quick installation guide | Yes |
AC adapter included | Yes |
Ethernet LAN (RJ-45) ports | 2 |
