Certification | CE, UKCA, FCC, RoHS, REACH |
Product colour | Black |
Maximum data transfer rate | 10200 Mbit/s |
Housing material | Metal |
HDCP | Yes |
Audio codecs | Dolby Digital 2/5.1, DTS-HD |
Maximum Resolution | 4096 x 2160 pixels |
HDMI version | 1.4 |
Input Impedance | 100 Ω |
HDCP version | 1.4 |
Supported chroma subsampling | 4:4:4 |
Supported sample rates | 192 kHz |
Accuracy | 0.1 dB |
CEC pass-through | Yes |
Compliance certificates | RoHS |
Output impedance | 100 Ω |
Chipset | EP91A2E |
HDMI pass-through | Yes |
Audio recording formats | LPCM |
Power consumption (typical) | 5 W |
Power note | 5.5/2.1mm DC |
Operating relative humidity (H-H) | 10 - 90% |
Storage temperature (T-T) | -20 - 60 °C |
Operating temperature (T-T) | -15 - 55 °C |
Depth | 88 mm |
Weight | 118 g |
Height | 24 mm |
Width | 65 mm |
CABLES INCLUDED | DC to USB Type-A |
PACKAGE WEIGHT | 250 g |
Manual | Yes |
Package depth | 144 mm |
Package Type | Box |
Quantity | 1 |
Package height | 55 mm |
Package width | 202 mm |
Harmonized System (HS) code | 85176990 |
DC-in jack | Yes |
HDMI in | 1 |
S/PDIF out port | Yes |
Digital audio optical out | 1 |
Number of HDMI outputs | 1 |
Audio (L/R) out | 1 |
Digital audio coaxial out | 1 |
