Services | |
SFP Transceiver-Typ | Faseroptik |
Maximum data transfer rate | 10000 Mbit/s |
interface | SFP+ |
Eigenschaft | Hot-Plug-Unterstützung |
Optical cable connector | LC |
Unterstützte Faserkabeldurchmesser (Kern/Mantel) | 50/125,62.5/125 µm |
SFP-Transceiver-Standard | SR |
Maximum possible transmission distance | 550 m |
wavelength | 850 nm |
Tx-Leistung (min) | -6,5 dBmW |
Tx-Leistung (max) | -1 dBmW |
Rx-Leistung (max) | -11,1 dBmW |
Rx-Leistung (min) | -1 dBmW |
Link-Budget | 10,1 dB |
mesh standard | IEEE 802.3ae |
Ethernet cable cabling technology | 10GBASE |
Duplex-System | Voll |
features | |
Product color | Gold, Metallisch |
Mean Time Between Failures (MTBF) | 3960000 h |
energy | |
Maximale Spannung | 3,3 V |
current (maximum) | 300 A |
certificates | |
Konformitätsbescheinigungen | RoHS |
safety | UL, TUV, CDRH |
certification | CE, FCC, VCCI, C-Tick, MSA |
operating conditions | |
operating temperatur | 0 - 70 °C |
Storage temperature range | -40 - 85 °C |
Operating relative humidity | 5 - 85% |
humidity during storage | 5 - 95% |
weight and dimensions | |
broad | 14,8 mm |
depth | 11,8 mm |
height | 56,5 mm |
Weight | 18 g |
package weight | 64 g |
logistic data | |
shipping carton length | 36 cm |
shipping carton width | 26 cm |
shipping carton height | 31 cm |
Net weight of shipping carton | 3,2 kg |
Quantity per shipping carton | 50 Stück(e) |
Pallet length (gross) | 102 cm |
Pallet width (gross) | 122 cm |
Weight (inner) shipping carton | 4,2 kg |
Goods tariff number (HS) | 85369010 |
