management functions | |
Switch-Typ | Managed |
switch level | L2/L2+ |
Eigenschaft | Benutzerhandbuch |
connections and interfaces | |
Number of basic switching RJ-45 Ethernet ports | 16 |
Basic Switching RJ-45 Ethernet Ports-Typ | Gigabit Ethernet (10/100/1000) |
Quantity of SFP module slots | 2 |
network | |
Ethernet LAN data transfer rates | 10,100,1000 Mbit/s |
data transmission | |
Routing/Switching Capacity | 26,78 Gbit/s |
Transferrate | 26,78 Mpps |
MAC-Adressentabelle | 8000 Eintragungen |
Jumbo-Frames | 9 |
Data packet buffer memory | 4,1 MB |
safety | |
DHCP functions | DHCP client, DHCP relay, DHCP snooping |
authentication | MAC-basierte Authentifizierung, Port-basierte Authentifizierung |
multicast capabilities | Multicast-Weiterleitung |
Design | |
form factor | 1U |
Product color | Schwarz |
certification | CE, FCC, RoHS |
energy | |
energy source | DC/PoE |
AC input voltage | 100 - 240 V |
AC input frequency | 50/60 Hz |
Power consumption (max.) | 181,4 W |
Power Over Ethernet (PoE) | |
Overall Power over Ethernet (PoE) | 150 W |
operating conditions | |
operating temperatur | 0 - 50 °C |
Storage temperature range | -40 - 70 °C |
Operating relative humidity | 10 - 90% |
humidity during storage | 5 - 90% |
heat dissipation | 619,06 BTU/h |
weight and dimensions | |
broad | 440 mm |
depth | 180 mm |
height | 44 mm |
Supplied cables | LAN (RJ-45) |
packaging type | Box |
