management functions | |
Switch-Typ | Managed |
switch level | L2/L3 |
connections and interfaces | |
Number of basic switching RJ-45 Ethernet ports | 16 |
Basic Switching RJ-45 Ethernet Ports-Typ | Gigabit Ethernet (10/100/1000) |
Quantity of SFP module slots | 2 |
network | |
mesh standard | IEEE 802.3af, IEEE 802.3at |
Eigenschaft | Power over Ethernet (PoE) |
data transmission | |
Routing/Switching Capacity | 36 Gbit/s |
passage | 18000 Mpps |
Transferrate | 26,78 Mpps |
safety | |
authentication type | IEEE 802.1x, RADIUS |
Design | |
form factor | 1U |
Product color | Silber |
LED indicators | Aktivität, Link, PoE, Geschwindigkeit, System |
certification | CE, FCC, IC |
energy | |
AC input voltage | 100 - 240 V |
AC input frequency | 50 - 60 Hz |
DC input voltage | 44 - 57 V |
Power Over Ethernet (PoE) | |
Number of Power over Ethernet plus (PoE+) ports | 8 |
Power over Ethernet (PoE) performance per port | 32 W |
Overall Power over Ethernet (PoE) | 48 W |
operating conditions | |
operating temperatur | -5 - 40 °C |
Operating relative humidity | 10 - 90% |
weight and dimensions | |
broad | 442,4 mm |
depth | 200 mm |
height | 43,7 mm |
Weight | 2,8 kg |
logistic data | |
Goods tariff number (HS) | 85176990 |
