management functions | |
Switch-Typ | Managed |
switch level | L3 |
connections and interfaces | |
Number of basic switching RJ-45 Ethernet ports | 16 |
Basic Switching RJ-45 Ethernet Ports-Typ | Gigabit Ethernet (10/100/1000) |
Number of Gigabit Ethernet (copper) ports | 12 |
Number of 2.5G Ethernet (copper) ports | 4 |
Quantity of module slots SFP+ | 2 |
power plug | DC-Anschluss |
network | |
mesh standard | IEEE 802.1x |
Eigenschaft | Montageblöcke enthalten |
Virtual LAN functions | Voice VLAN |
data transmission | |
Routing/Switching Capacity | 84 Gbit/s |
throughput | 42 Gbit/s |
Transferrate | 62,496 Mpps |
safety | |
DHCP functions | DHCP snooping, DHCPv6 relay |
multicast capabilities | |
Design | |
Product color | Grau |
housing material | Stahl |
LED indicators | System |
Display-Typ | LCM |
energy | |
energy source | AC/DC |
AC input voltage | 100 - 240 V |
AC input frequency | 50/60 Hz |
DC input voltage | 44 - 57 V |
Power consumption (max.) | 30 W |
Power Over Ethernet (PoE) | |
Number of Power over Ethernet plus (PoE+) ports | 12 |
Anzahl der Power over Ethernet 4PPoE- (PoE++) Anschlüsse | 4 |
Power over Ethernet (PoE) performance per port | 15 W |
Overall Power over Ethernet (PoE) | 180 W |
operating conditions | |
operating temperatur | -5 - 40 °C |
Operating relative humidity | 10 - 90% |
weight and dimensions | |
broad | 325,1 mm |
depth | 160 mm |
height | 43,7 mm |
Weight | 2,1 kg |
scope of delivery | |
Supplied cables | Leistung |
certificates | |
Konformitätsbescheinigungen | CE, Eidgenössische Kommunikationskommission (FCC), Industry Canada (IC) |
