management functions | |
Switch-Typ | Unmanaged |
Eigenschaft | Ventilatorlos |
connections and interfaces | |
Number of basic switching RJ-45 Ethernet ports | 16 |
Basic Switching RJ-45 Ethernet Ports-Typ | Gigabit Ethernet (10/100/1000) |
network | |
mesh standard | IEEE 802.1p, IEEE 802.3az, IEEE 802.3x |
Copper Ethernet cabling technology | 1000BASE-T |
data transmission | |
Routing/Switching Capacity | 32 Gbit/s |
MAC-Adressentabelle | 8000 Eintragungen |
number of queues | 8 |
Jumbo-Frames | 9216 |
Packet water supply system (1 Gbit / s) | 1488000 pps |
Packetweiterleitungsrate (100 Mbit / s) | 148800 pps |
Packetweiterleitungsrate (10 Mbit / s) | 14880 pps |
Data packet buffer memory | 0,512 MB |
Design | |
Product color | Schwarz |
LED indicators | Aktivität, Link, Leistung, Geschwindigkeit |
Services | |
Mean Time Between Failures (MTBF) | 564658 h |
energy | |
DC input voltage | 12 V |
input current | 1 A |
Power consumption (max.) | 8,89 W |
operating conditions | |
operating temperatur | 0 - 40 °C |
Storage temperature range | -40 - 70 °C |
Operating relative humidity | 10 - 90% |
humidity during storage | 5 - 95% |
heat dissipation | 30,32 BTU/h |
weight and dimensions | |
broad | 280 mm |
depth | 110 mm |
height | 25 mm |
Weight | 770 g |
certificates | |
certification | CE, FCC, ICES 003, RCM |
