management functions | |
Switch-Typ | Managed |
switch level | L2/L2+ |
Eigenschaft | Schnellstartübersicht |
MIB support | Yes |
connections and interfaces | |
Number of basic switching RJ-45 Ethernet ports | 16 |
Basic Switching RJ-45 Ethernet Ports-Typ | Gigabit Ethernet (10/100/1000) |
Number of Gigabit Ethernet (copper) ports | 16 |
Quantity of SFP module slots | 2 |
network | |
mesh standard | IEEE 802.3ab, IEEE 802.3i, IEEE 802.3u, IEEE 802.3z |
Ethernet LAN data transfer rates | 10,100,1000 Mbit/s |
Virtual LAN functions | Port-based VLAN, Private VLAN, Protocol-based VLAN, Tagged VLAN, Voice VLAN |
Number of VLANs | 4000 |
data transmission | |
Routing/Switching Capacity | 36 Gbit/s |
Transferrate | 26,8 Mpps |
MAC-Adressentabelle | 8000 Eintragungen |
Number of static routes | 32 |
Number of IP interfaces | 16 |
Jumbo-Frames | 9000 |
Data packet buffer memory | 4,1 MB |
safety | |
DHCP functions | DHCP client, DHCP relay, DHCP server, DHCP snooping, DHCPv6 client, DHCPv6 snooping |
multicast capabilities | |
logs | |
management logs | SNMPv1/v2c/v3, SNTP |
Design | |
form factor | 1U |
Product color | Schwarz |
Services | |
energy | |
energy source | AC |
AC input voltage | 100 - 240 V |
AC input frequency | 50/60 Hz |
Power consumption (max.) | 12,3 W |
operating conditions | |
operating temperatur | 0 - 40 °C |
Storage temperature range | -40 - 70 °C |
Operating relative humidity | 10 - 90% |
humidity during storage | 5 - 90% |
heat dissipation | 41,97 BTU/h |
weight and dimensions | |
broad | 440 mm |
depth | 180 mm |
height | 44 mm |
scope of delivery | |
Supplied cables | AC, LAN (RJ-45) |
certificates | |
certification | CE, FCC, RoHS |
