management functions | |
Switch-Typ | Unmanaged |
connections and interfaces | |
Number of basic switching RJ-45 Ethernet ports | 16 |
Basic Switching RJ-45 Ethernet Ports-Typ | Gigabit Ethernet (10/100/1000) |
Number of Gigabit Ethernet (copper) ports | 16 |
power plug | AC-Eingangsbuchse |
network | |
mesh standard | IEEE 802.3ab, IEEE 802.3u, IEEE 802.3x |
Copper Ethernet cabling technology | 10BASE-T, 100BASE-TX, 1000BASE-TX, 1000BASE-T |
supported cable types | Cat3, Cat4, Cat5, Cat5e |
Eigenschaft | Nachhaltigkeitskonformität |
data transmission | |
Routing/Switching Capacity | 32 Gbit/s |
Transferrate | 23,8 Mpps |
MAC-Adressentabelle | 8000 Eintragungen |
Jumbo-Frames | 10000 |
logs | |
Supported network protocols | CSMA/CD, TCP/IP |
Design | |
Product color | Schwarz |
Services | |
Compatible operating systems | Microsoft Windows 2000/XP/2003/Vista/2008/7/2012/8/10MacOSNetWareUNIXLinux |
Maximum cable length | 100 m |
Technical details | |
Konformitätsbescheinigungen | CE, Eidgenössische Kommunikationskommission (FCC), RoHS |
energy | |
energy source | AC |
AC input voltage | 100 - 240 V |
AC input frequency | 50/60 Hz |
Power consumption (max.) | 9,26 W |
operating conditions | |
operating temperatur | 0 - 40 °C |
Storage temperature range | -40 - 70 °C |
Operating relative humidity | 10 - 90% |
humidity during storage | 5 - 90% |
heat dissipation | 31,6 BTU/h |
weight and dimensions | |
broad | 294 mm |
depth | 180 mm |
height | 44 mm |
Supplied cables | AC |
packaging type | Box |
package weight | 1,85 kg |
sustainability | |
logistic data | |
Goods tariff number (HS) | 85176990 |
