management functions | |
Switch-Typ | Managed |
switch level | L2 |
Eigenschaft | Nachhaltigkeitskonformität |
connections and interfaces | |
Number of basic switching RJ-45 Ethernet ports | 16 |
Basic Switching RJ-45 Ethernet Ports-Typ | Gigabit Ethernet (10/100/1000) |
Number of Gigabit Ethernet (copper) ports | 16 |
power plug | AC-Eingangsbuchse |
network | |
mesh standard | IEEE 802.1p, IEEE 802.1Q, IEEE 802.3, IEEE 802.3ab, IEEE 802.3u, IEEE 802.3x |
Copper Ethernet cabling technology | 100BASE-TX, 100BASE-T, 1000BASE-T |
supported cable types | Cat3, Cat5, Cat6 |
Virtual LAN functions | Port-based VLAN, Tagged VLAN |
Number of VLANs | 32 |
data transmission | |
Routing/Switching Capacity | 32 Gbit/s |
Transferrate | 23,8 Mpps |
MAC-Adressentabelle | 8000 Eintragungen |
number of queues | 4 |
Jumbo-Frames | 9000 |
Data packet buffer memory | 0,512 MB |
safety | |
Design | |
form factor | 1U |
Product color | Schwarz |
housing material | Metall |
Services | |
Compatible operating systems | Windows |
Maximum cable length | 100 m |
Technical details | |
Konformitätsbescheinigungen | CE, Eidgenössische Kommunikationskommission (FCC), RoHS |
energy | |
energy source | AC |
AC input voltage | 100 - 240 V |
AC input frequency | 50/60 Hz |
Power consumption (max.) | 19,15 W |
operating conditions | |
operating temperatur | 0 - 40 °C |
Storage temperature range | -40 - 70 °C |
Operating relative humidity | 10 - 90% |
humidity during storage | 5 - 90% |
heat dissipation | 34,52 BTU/h |
weight and dimensions | |
broad | 284 mm |
depth | 180 mm |
height | 44 mm |
Supplied cables | AC |
packaging type | Box |
package weight | 1,91 kg |
sustainability | |
